Descriptions of the Control Panel Keys

(2) TIME/DIV
+ + ENTER
Password setting
(12) CURSOR
(11) FILE/GROUP
1
. SPAN/POSI/TRACE
This key enables SPAN, POSITION, and TRACE settings to be made
independently fo reach channel. Each time this key is pressed, the display mode
changes in the sequence shown below. Use the
channel, and the
MONITOR
SPAN
POSITION
TRACE
2
. TIME/DIV
Press the [TIME/DIV] key to change the time axis display range on the waveform
screen.
6
(4) QUIT
(ALARM CLEAR)
(10) REVIEW
and keys to change the setting values.
Points to Remember
Displays digital values (default).
Used to change span settings (change the waveform amplitude).
Used to change position settings (adjust the upper and lower values
of the waveform).
Used to change trace settings (set the waveform display to On or Off).
* If the [QUIT] key is pressed when the GL240 is in the SPAN, POSITION, or
TRACE mode, the display returns to MONITOR mode.
(1) SPAN/POSI/TRACE
(3) MENU
(5) DIRECTION KEYS
(6) ENTER
(7) FAST FORWARD
(8) START/STOP
(9) DISPLAY
and keys to select the
(KEY LOCK)
(USB DRIVE MODE)
