GRAPHTEC midi LOGGER GL240 Quick Start Manual page 14

12
4. Press the [MENU] key and open the "DATA" menu.
5. Set the sampling interval to "1s".
Move the cursor to "Sampling" and then select "1s".
6. Set the Data Capture Destination to "SD memory card".
Here the "TEST" folder is created in the internal memory (SD1), and then
destination for the captured data is set to the TEST folder.
(1) Move the cursor to the File Name parameter and then press the [ENTER]
key.
(2) The data saving destination box shown in the following screen opens.
In the data saving destination box, set the SD1 as a capture destination.
(3) Move into the folder by pressing the [ ] key and move the cursor to the
"Create New Folder" and then press the [ENTER] key. The Folder Name
Input menu is displayed.
(4) A text input box is displayed. Let's create a folder named "TEST".
(1) In the text type select; delete; insert; confirm items, move the cursor
to the A using the
(2) The selected text is displayed.
In the text select, move the cursor to the text using the
keys and then press the [ENTER] key.
Input "TEST", move the cursor to [OK] , and then press the [ENTER] key
to enter your setting.
and keys.
Text input box
(1) Select the text type, delete,
insert, confirm
(2) Select the character
, , and
