2. Setup : How to Make the Settings

Make the settings required for data capture. Here we will make only those settings
that are minimum requirement. The other settings will be not changed from the
factory default settings.
Basic Setup Menu Operation
The , [ENTER], and [QUIT] keys are used to set the condition on the setup menu.
The current position of the cursor on the setup menu is displayed in green.
Use the
position, a selection menu or a box of entering value is displayed.
If you press the [QUIT] key, the screen closes and the settings are canceled.
•
Examples of selection menu operations (AMP screen)
1. Use the keys to move
the cursor to the Input
parameter of CH 1 and then
press the [ENTER] key.
(Note: Select "DC" for voltage measurement, and "TEMP" for temperature measurement.)
Points to Remember
keys to move the cursor. When the [ENTER] key is pressed at the cursor
2. A selection menu is displayed
when the [ENTER] key is
pressed. Use the
to select "TEMP."
1. Press the [MENU] key to display the setup menu screen.
2. Set Input to "DC" and Range to "1V" for CH1,
and set Input to "TEMP" and Sensor to "TC-T" for CH2.
(1) Move the cursor to CH1 "Input" and select "DC" and then move it to
"Range" and select "1V".
(2) In the same way, move the cursor to CH2 "Sensor" and select "TC-T".
3. Select "Off" for all the other channels.
(1) Using the procedure described above, select "Off" for CH 3 to CH 10.
3. Press the [ENTERv key to
confirm your selection.
and keys
11
