GRAPHTEC midi LOGGER GL240 Quick Start Manual page 10

8
. START/STOP (USB DRIVE MODE)
Press the [START/STOP] key to perform start and stop of a data capture while the
GL240 is in the Free Running status.
If this key is held down while the power to the GL240 is turned on, the GL240 is
switched the USB to the Drive Mode.
* For more information about the Drive Mode of the USB, refer to the User's Manual in the supplied
CD.
9
. DISPLAY
Press the [DISPLAY] key
Waveform + Digital
Expanded Waveform
Digital + Calc
10
. REVIEW
Press the [REVIEW] key to replay captured data. If the GL240 is in the Free
Running status, data files that have already been captured are replayed. If the
GL240 is still capturing data, the data is replayed in a 2-screen format.
* A data replay operation will not be performed if data has not been captured.
11
. FILE
It is used to operate the internal memory (SD1) and SD memory card (SD2), or
replace the SD memory card (SD2).
12
. CURSOR (ALARM CLEAR)
Press the [CURSOR] key to switch between the A and B cursors during a data
replay operation.
If the Alarm setting has been specified as "Alarm Hold", press this key to clear the
alarm.
The alarm settings are made in the "TRIG" menu.
8
Points to Remember
•
Waveform + Digital
This is the default screen when the GL240 is turned on,
and both waveforms and digital values are displayed.The
screen settings can also be changed by using the
[SPAN/POSI/TRACE] key.
•
Expanded Waveform
Displays waveforms only.
•
Digital + Calc
Displays large-size digital values and two types of
calculation processing results. The calculation settings are
made in the "DATA" menu.
Use the key or
modes.
* For more information, refer to the User's Manual in the
supplied CD.
key to switch digital display
