p-4 Overview
Catalog Number
Explanation
1-3 4 5
20P 4 1
a b c
a
Drive
Code Type
20P PowerFlex DC
b
Motor Operation
Code Type
2 Two Quadrant Operation
4 Four Quadrant Operation
c
Input Type
Code Type
1 6 Pulse
2 12 Pulse
d
Enclosure
Code Enclosure Rating
A IP20, NEMA/UL Type Open
IP43, NEMA/UL Type 1 -
B
Filter
G IP54, NEMA/UL Type 12
IP54, NEMA/UL Type 12 -
H
Fan/Filter
N IP00, NEMA/UL Type Open
e
Input Voltage
Code Voltage
B 230V ac
C 400V ac
D 460V ac
E 600V ac
F 690V ac
PowerFlex Digital DC Drive User Manual -
6 7 8-10
A D 4P1
d e f
Code Hp
7P0 1.5
9P0 2
012 3
020 5
029 7.5
038 10
055 15
073 20
093 25
110 30
146 40
180 50
218 60
265 75
360 100
434 125
521 150
Conform.
Coat
No
No Code Hp
No
4P1 2
6P0 3
No
010 5
No
014 7.5
019 10
027 15
035 20
045 25
052 30
073 40
086 50
100 60
129 75
167 100
207 125
250 150
330 200
412 250
495 300
667 400
Publication 20P-UM001C-EN-P - July 2008
Position
11 12
R N
g h
f1
230V, 60 Hz Input
Armature Field
Frame
Amps Amps
7 A 10
9 A 10
12 A 10
20 A 10
29 A 10
38 A 10
55 A 10
73 A 14
93 A 14
110 A 14
146 B 20
180 B 20
218 B 20
265 B 20
360 B 20
434 B 20
521 C 20
f2
460V, 60 Hz Input
Armature Field
Frame
Amps Amps
4.1 A 10
6 A 10
10 A 10
14 A 10
19 A 10
27 A 10
35 A 10
45 A 10
52 A 10
73 A 14
86 A 14
100 A 14
129 A 14
167 B 20
207 B 20
250 B 20
330 B 20
412 B 20
495 C 20
667 C 20
13 14 15
0 N N
i j k
g
Field Supply
Code Type
A Three-Phase Regulated
F Fixed Field w/Economy
R Single-Phase Regulated
h
Packaging/Documentation
Code Shipping Carton User Manual
0 No
A Yes
N Yes
Q No
i
HIM
Code Operator Interface
0 Blank Cover
Standard - for additional selections, refer to the
PowerFlex Digital DC Drive Technical Data,
publication 20P-TD001. . .
j
I/O Options
Code Control
I/O Expansion Card (4 Additional 24V
A dc Digital Inputs & Outputs, 2 Analog
Outputs)
115V ac Conversion Card (8 Digital
B
Inputs & Outputs)
I/O Expansion Card + 115V ac
C
Conversion
None (8 - 24V dc Digital Inputs &
N Outputs, 3 Analog Outputs and 2
Analog Inputs are Standard)
k
Communication Options
Code Description
N None
Standard - for additional selections, refer to the
PowerFlex Digital DC Drive Technical Data,
publication 20P-TD001. . .
l
Cabinet Options
Code Type
N None
16
N
l
No
Yes
No
Yes
