Parameter Name & Description
See page 3-2 for symbol descriptions
1393 [Inversion Relay1]
Inverts the signal for Relay Output 1.
A
1323 [DPI P1 Select]
Selects the destination of the reference value from DPI Port 1.
1324 [DPI P2 Select]
Selects the destination of the reference value from DPI Port 2.
1325 [DPI P3 Select]
Selects the destination of the reference value from DPI Port 3.
1326 [DPI P4 Select]
Selects the destination of the reference value from DPI Port 4.
1327 [DPI P5 Select]
Selects the destination of the reference value from DPI Port 5.
Programming and Parameters
Values
Default: 0 = "Disabled"
Options: 0 = "Disabled"
1 = "Enabled"
Default: 0 = "Off"
Options: 0 = "Off"
1 = "Speed Ref A"
2 = "Speed Ref B"
3 = "Trim Ramp"
4 = "Trim Speed"
5 = "Torque Ref"
6 = "Trim Torque"
7 = "Pos Cur Lim"
8 = "Neg Cur Lim"
Refer to Par 1323 [DPI P1 Select].
Refer to Par 1323 [DPI P1 Select].
Refer to Par 1323 [DPI P1 Select].
Refer to Par 1323 [DPI P1 Select].
PowerFlex Digital DC Drive User Manual -
3-71
Publication 20P-UM001C-EN-P - July 2008
