A-20 Supplemental Drive Information
AC
Drive Cat. DC Line
No. Amps Amps
20P-41AD4P1 4.1 3.3
20P-41AD6P0 6 4.9
20P-41AD010 10 8.2
20P-41AD014 14 11.4
20P-41AD019 19 15.5
20P-41AD027 27 22.1
20P-41AD035 35 28.6
20P-41AD045 45 36.8
20P-41AD052 52 42.5
20P-41AD073 73 59.6
20P-41AD086 86 70.3
20P-41AD100 100 81.7
20P-41AD129 129 105.4
20P-41AD167 167 136.4
20P-41AD207 207 169.1
20P-41AD250 250 204.3
20P-41AD330 330 269.6
20P-41AD412 412 336.6
20P-41AD495 495 404.4
20P-41AD667 667 544.9
(1)
HUBBELL_Y95W808GB - Must be sourced separately from drive.
(2)
HUBBELL_Y101W595GB - Must be sourced separately from drive.
(3)
HUBBELL_Y109W542GB - Must be sourced separately from drive.
(4)
Coil voltage = 115V AC, 50/60Hz.
(5)
ABB_EHDB360C-1L-22 - ABB Contactor for drives with a dynamic brake. Must be sourcing separately from drive.
(6)
ABB_EHDB520C2P-1L - ABB contactor for drives with no dynamic brake. ABB_EHDB520C-1L - ABB contactor for drives with a dynamic brake. Must be sourced separately from drive.
(7)
ABB_EHDB650C2P-1L - ABB contactor for drives with no dynamic brake. ABB_EHDB650C-1L - ABB contactor for drives with a dynamic brake. Must be sourced separately from drive.
(8)
ABB_EHDB800C2P-1L - ABB contactor for drives with no dynamic brake. ABB_EHDB800C-1L - ABB contactor for drives with a dynamic brake. Must be sourced separately from drive.
(9)
See DC Contactor Crimp Lug Kit Specifications on page A-21
(10)
Wire and Lug size dependant on Cabinet dims and local codes.
PowerFlex Digital DC Drive User Manual -
Table A.S 460V AC Input, Regenerative Drives
Dynamic
Brake Armature
Resistor Kit Voltage
HP Cat. No. (Volts)
2 1370-DBH63 500
3 1370-DBH64 500
5 1370-DBH65 500
7.5 1370-DBH66 500
10 1370-DBH67 500
15 1370-DBH68 500
20 1370-DBH69 500
25 1370-DBH70 500
30 1370-DBH71 500
40 1370-DBH72 500
50 1370-DBH73 500
60 1370-DBH74 500
75 1370-DBH75 500
100 1370-DBH76 500
125 1370-DBH77 500
150 1370-DBH78 500
200 1370-DBH79 500
(1)
250 500
(2)
300 500
(3)
400 500
for more information.
Publication 20P-UM001C-EN-P - July 2008
DB Brake
Resistor DB Resistor Amps
Size (ohms) Size (Watts) Required
81 255 6.17
62 245 8.06
45 245 11.11
27 350 18.52
20 420 25.00
12 405 41.67
5 330 100.00
4.5 330 111.11
3.5 385 142.86
2.6 345 192.31
2 345 250.00
2 345 250.00
1 270 500.00
0.7 280 714.29
0.7 280 714.29
0.5 365 1000.00
0.7 280 714.29
0.808 7292 –
0.595 6069 –
0.542 6439 –
DC Loop DC Contactor
Contactor Cat. Crimp Lugs Cat.
(4) (9)
No. No.
1370-DC56 1370-LG40
1370-DC56 1370-LG40
1370-DC56 1370-LG40
1370-DC56 1370-LG40
1370-DC56 1370-LG40
1370-DC56 1370-LG40
1370-DC56 1370-LG40
1370-DC56 1370-LG52
1370-DC56 1370-LG52
1370-DC110 1370-LG92
1370-DC110 1370-LG92
1370-DC110 1370-LG110
1370-DC180 1370-LG140
1370-DC180 1370-LG180
1370-DC280 1370-LG228
1370-DC280 1370-LG268
(5) (10)
(6) (10)
(7) (10)
(8) (10)
