Lifting PowerFlex DC Drives

Figure 1.4 Frame C Approximate Dimensions
A A1 B
mm (in.) mm (in.) mm (in.)
521 (20.5) 499 (19.7) 511 (20.1) 400 (15.7) 200 (7.9)
B4
B1
B
B2
B3
Table 1.C Frame C Weights
Drive w/ND Rating Code
230V 460V
– 495
521 667
The dimensions and weights specified above must be taken into
consideration when mounting the device. Use the proper equipment to
safely lift and hold the weight of the drive while mounting.
ATTENTION: To guard against possible personal injury or
!
equipment damage . . .
• Inspect all lifting hardware for proper attachment before lifting
the drive.
• Do Not allow any part of the drive or lifting mechanism to
make contact with electrically charged conductors or
components.
• Do Not subject the drive to high rates of acceleration or
deceleration while transporting to the mounting location or
when lifting.
• Do Not allow personnel or their limbs directly underneath the
drive when it is being lifted and mounted.
B1 B2
mm (in.) mm (in.)
A1
PORT
MOD
NET A
NET B
STS
A
Weight - Regenerative Drives
Drive Drive & Packaging Drive
kg (lbs.) kg (lbs.)
61 (134.5) 74 (163.1)
65 (143.3) 81 (178.6)
PowerFlex Digital DC Drive User Manual -
Installation and Wiring
B3 B4 C
mm (in.) mm (in.) mm (in.)
55 (2.2) 56 (2.2) 416 (16.4)
C
Weight - Non-regenerative Drives
Drive & Packaging
kg (lbs.) kg (lbs.)
57 (125.7) 70 (154.3)
62 (136.7) 75 (165.3)
Publication 20P-UM001C-EN-P - July 2008
