4-8 Troubleshooting
PowerFlex Digital DC Drive User Manual -
Alarm Type Description
CntactrCflct
DigInCflctA
DigInCflctB
DigInCflctC
Encoder Loss
EncoderCflct
Publication 20P-UM001C-EN-P - July 2008
Contactor input functions are in conflict:
• When Par
1391 [ContactorControl] is set to "None", both relay outputs
(Pars 1392 [Relay Out 1 Sel] and
([Digital Inx Sel]) cannot be set to "Contactor" or "ContactorDB".
• With [ContactorControl] set to "Contactor", one relay output and one digital
input must be set to "Contactor". No output can be defined as
"ContactorDB".
• With [ContactorControl] set to "Contactor+DB", both relay outputs and one
digital input must be set to "Contactor", "ContactorDB" and "Contactor",
respectively.
Because any relay output can be configured as contactor or DB control and
any digital input as contactor status, care must be taken to correctly wire the
terminal blocks to match the parameter selections.
Digital input functions are in conflict. Combinations marked with a " " will
cause an alarm.
Acc2/Dec2 Accel 2 Decel 2 Jog 1/2 Jog Fwd Jog Rev Fwd/Rev
Acc2/Dec2
Accel 2
Decel 2
Jog 1/2
Jog Fwd
Jog Rev
Fwd/Rev
One of the following digital input conflicts exists:
• A digital Start input has been configured without a Stop input
• None of the digital inputs are configured for "Enable"
• Other digital input functions are in conflict. Combinations that conflict are
marked with a " " and will cause an alarm.
Stop-
Start CF Run Run Fwd Run Rev
Start
Stop-CF
Run
Run Fwd
Run Rev
Jog 1/2
Jog Fwd
Jog Rev
Fwd/Rev
More than one physical input has been configured to the same input function.
Multiple configurations are not allowed for the following input functions.
Forward/Reverse Run Reverse
Jog Forward Jog Reverse
Speed Select 2 Speed Select 3
Accel 2 Decel 2
The drive is not receiving a speed feedback signal from the encoder. Refer to
the "Encoder Loss" fault description on
One of the following has occurred:
• Par
414 [Fdbk Device Type] is set to 1 "Encoder" and Par
Out Sel] is not set to 0 "Off". If you are using an encoder, set Par
[Encoder Out Sel] to 0 "Off".
• More than one of the following parameters contains the same value: Pars
1021 [Encoder Out Sel], 70, 75
[DPI Px Select].
629 [Relay Out 2 Sel] and all digital inputs
Jog Fwd/
1/2 Jog Fwd Jog Rev Rev
Run Forward
Speed Select 1
Acc2 / Dec2
Run
page 4-4 for more information.
1021 [Encoder
and 80 [Anlg Inx Sel], and/or 1323
1021
- 1327
