ORDERING INFORMATION

BILL OF MATERIALS

Table 4.
Quantity Description
1 2.2 μF, 50 V, X5R, 0603, capacitor
1 SMD/SMT, 10 μF, 35 V, X7R, ±10%, 1206, capacitors
2 Ceramic capacitors, 10 μF, 50 V, X7R, 1210
1 SMD/SMT, X7R, 2 kV, 2200 pF, 10%, 1812, capacitor
1 Ceramic capacitor, 100 pF, 50 V, 10%, X7R, SMD, 0603, do
not install (DNI)
1 Ceramic capacitor, 1 μF, 16 V, 10%, X5R, SMD, 0603
3 2.2 μF, 50 V, X5R, 0603, capacitors
2 SMD/SMT, 50 V, 100 pF, 10%, capacitors, 0603
1 Ceramic capacitor, 10 nF, 100 V, 10%, X7R, SMD, 0603
2 Capacitors, 220 μF, 35 V, CPLRAD138D315H433LD24
3 0603, 470 pF, 100 V, X7R, 10%, capacitors
1 Ceramic capacitor chip, 22 μF, 10 V, 1206
1 Ceramic capacitor chip, 10 μF, C1206H71
1 Capacitor, 100 μF, 10 V, CPLRAD100D197H300LD20
1 Zener diode, 300 mW, ±5%, surface mount SOD-323-2
1 Diode, ultrafast, 100 V, 1 A, S1B, DO214AC-3
1 ESD suppressor/TVS diode, 400 W, 43 V, unidirect,
DO214AC_C
2 Schottky diodes and rectifiers, REC SOD123, 2 A, 200 V
1 Schottky diode and rectifier, 1 A, 60 V, SMA
1 Schottky diode and rectifier, 1 A, 40 V, SMA
1 Schottky diode and rectifier, 1 A, 100 V, SMA
1 CONN-PCB single row SMD terminal strip, 640454-2,
CNTHMHDR1x2l200W225h415_A
1 Wire short
1
CONN-PCB single row SMD terminal strip, 640454-4,
CNTHMHDR1X4L400W225H415_A
1 MOSFET power, 100 V, 4 A, 70 mΩ,
MLP6_2X2_PAD_9X1_PAD_2X_56
1 Transistor, NPN, 160 V, 0.8 A
1 SMD resistor, 5.1 kΩ, 1/8 W, 1%, 0603
1 SMD resistor, 10 kΩ, 1/8 W, 1%, 0603
1 1206, 10 mΩ, 1%, current sense resistor, 1210-4_A
1 SMD resistor, 33 kΩ, 1/8 W, 1%, 0603
1 SMD resistor, 30.1 kΩ, 1/8 W, 1%, 0603
1 SMD resistor, 10 Ω, 1/8 W, 1%, 0603
1 SMD resistor, 5.9 kΩ, 1/8 W, 1%, 0603
1 SMD resistor, 5.11 kΩ, 1/8 W, 1%, 0603
1 SMD resistor, 0.976 kΩ, 1/8 W, 1%, 0603
1 SMD resistor, 0.976 kΩ, 1/8 W, 1%, 0603
1 SMD resistor, 487 kΩ, 1/8 W, 1%, 0603
1 SMD resistor, 51.1 kΩ, 1/8 W, 1%, 0603
1 SMD resistor, 0 Ω, 1/8 W, jumper, 0603
1 SMD resistor, 4.75 kΩ, 1/8 W, 1%, 0603
1 SMD resistor, 33 kΩ, 1/8 W, 1%, 0603
1 SMD resistor, 10 Ω, 1/8 W, 1%, 0805
1 SMD resistor, 33 kΩ, 1/5 W, 0.1%, 0603
1 SMD resistor, 0 Ω, 1/8 W, jumper, DNI, 0603
User Guide
Reference
Designator
C1
C7
C24, C57
C32
C35
C36
C37, C38, C48
C39, C51
C40
C50, C67
C58, C59, C60
C62
C65
C66
D5
D11
D12
D16, D18
D19
D21
D22
J2
J3
J5
Q3
Q7
R12
R14
R15
R17
R18
R19
R20
R21
R23
R24
R27
R28
R29
R31
R35
R36
R49
R50
Rev. 0 | Page 11 of 13
Manufacturer Part
1
Manufacturer Number
Murata GRT188R61H225KE13D
Taiyo Yuden GMK316AB7106KL-TR
AVX Corp 12105C106KAT2A
TDK C4532X7R3D222K130KA
AVX Corp 06035C102KAT2A
Murata GRM185R61C105KE44D
Murata GRT188R61H225KE13D
Kemet C0603C101K5RACTU
AVX Corp C0603C103K2RACTU
Panasonic EEUFM1V221
Murata GRM188R72A471KA01D
Murata GRM31CR71A226ME15L
Taiyo Yuden GMK316AB7106KL-TR
Panasonic EEUFM1A101
On Semiconductor SZMM3Z11VT1G-ND
Fairchild S1B
Vishay P4SMA43A-E3/5A
On Semiconductor MBR2H200SFT1G
On Semiconductor MBRA160
On Semiconductor MBRA140T3G
On Semiconductor MBRA1H100
TE Connectivity 640454-2
TE Connectivity 640454-4
Fairchild STL3N10F7
Semiconductor
Fairchild FMBS2383
Vishay Dale ERJ-8BWFR010V
AVX 08051C471KAZ2A
UG-1384
