EVALUATION BOARD HARDWARE

EVALUATION BOARD CONFIGURATIONS

The ADP1071-1EVALZ is preconfigured with the default
settings to operate the power supply at the rated load. No
additional configuration is necessary. Replace J3 with at
least an AWG22 wire to monitor the primary current.

POWERING UP

To power up the ADP1071-1EVALZ, use the following steps:
1. Connect a dc source (voltage range of 18 V
the input terminals and electronic loads at the output
terminals.
2. Connect voltmeters on the input terminals (VIN+ and
VIN−) and output terminals (+24 V, +5.5 V, −15 V, and
GND) separately.
3. Connect the voltage probes at different test pins. Use the
differential probes and ensure the ground of the probes are
isolated if the measurements are made on the primary and
secondary side of the transformer (T1) simultaneously.
4. Set the electronic load to the maximum rating for each rail.
5. Turn on the dc source.

ADP1071-1EVALZ DIMENSIONS

Table 2 shows the dimensions of the ADP1071-1EVALZ
evaluation board. The dimensions exclude standoff.
Table 2. Evaluation Board Dimensions
Dimension
Length
Width
Height
to 32 V ) at
DC DC
Rev. 0 | Page 4 of 13
ADP1071-1EVALZ
Value (Inches)
1.9
1.25
0.75 (excluding standoffs)
