SIMATIC
Industrial PC
SIMATIC IPC347E
Operating Instructions
09/2018
A5E41134132-AE
___________________
Preface
___________________
Overview
___________________
Safety instructions
___________________
Installing and connecting the
device
___________________
Commissioning the device
___________________
Installing hardware
expansions
___________________
Device maintenance
___________________
Technical specifications
___________________
Appendix Motherboard
___________________
Appendix BIOS
___________
Appendix The pin definition
of ATX power supply output
connector
___________________
Appendix Technical support
___________________
Appendix List of
abbreviations
1
2
3
4
5
6
7
A
B
C
D
E

Advertisement

   Summary of Contents for Siemens SIMATIC IPC347E

  • Page 1 ___________________ Preface ___________________ Overview ___________________ SIMATIC Safety instructions ___________________ Installing and connecting the device Industrial PC SIMATIC IPC347E ___________________ Commissioning the device ___________________ Installing hardware expansions Operating Instructions ___________________ Device maintenance ___________________ Technical specifications ___________________ Appendix Motherboard ___________________ Appendix BIOS...
  • Page 2 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
  • Page 3: Preface

    ● service and maintenance personnel who install add-ons or carry out fault/error analyses. Validity of the Operating Instructions These operating instructions are valid for all supplied versions of the SIMATIC IPC347E. The updates of the document will be published on the Siemens technical support (https://support.industry.siemens.com).
  • Page 4 Comments 02/2016 The first edition 08/2017 The second edition 10/2017 The third edition 07/2018 Add the workaround for the Windows boot problem caused by SATA selection. 09/2018 Add the information that complies with UL61010. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 5: Table Of Contents

    Disk drives ........................45 5.3.1 Installation options for drives ..................... 45 5.3.2 Removing the drive module ....................45 5.3.3 Installing drives or hard disks ..................... 46 5.3.4 Removing and installing internal hard disks ............... 48 SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 6 Internal USB 2.0 connector (USB 2_56 & USB 2_78) ............89 A.3.4 Internal RS-232 COM Connector (COM3 & COM4) ............90 A.3.5 Internal DIO Connector (DIO1) ...................91 A.3.6 Internal LPT Connector (LPT1 – Parallel Port) ..............92 SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 7 Appendix The pin definition of ATX power supply output connector ..........121 Appendix Technical support ....................123 Service and support......................123 Problem solving ........................124 D.2.1 General information ......................124 Appendix List of abbreviations ....................127 Glossary ..........................133 Index ........................... 145 SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 8 Table of contents SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 9: Overview

    Overview Product description The SIMATIC IPC347E is an industrial PC in 19" rack format design (4U). ● Powerful processors up to Intel Core i5 (4th generation) ● No additional dust protection measures required thanks to filter mat and overpressure ventilation ●...
  • Page 10 Overview 1.1 Product description SIMATIC IPC347E configuration plan Type 19" rack, 4 U • Mounting support horizontal installation • Chipset Intel® H81 • CPU type Intel® Pentium® Dual Core™ G3420 (2C/2T; 3.2 GHz; 3 MB cache) • Intel® Core™ i5-4570S (4C/4T; 2.9 (3.6) GHz; 6 MB cache) •...
  • Page 11: Design Of The Device

    Display Meaning Description ⑨ Display for hard disk access No accessing Green flashing Accessing data ⑩ Power PC operating status display Hibernate, switched off or unplugged Green PC is in operation. Green flashing standby SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 12 Air outlet ④ Interfaces ⑤ Extensible interface ⑥ Expansion slots for: • 4 × PCI • 1 × PCle × 1 • 1 × PCIe x 8 (2 lanes) • 1 × PCIe x 16 SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 13 See the pin assignment below. Each of the USB port can be disabled/enabled separately by disabling/enabling its associated USB port in BIOS. On how to disable the USB port, see USB configuration in Advanced setup (Page 104). SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 14 Status Description no link established link speed 10Mbps Orange link established link speed 100Mbps Blink transferring data Green link speed 1Gbps Power supply The following figure shows the connector for the IPC347E power supply. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 15: Operator Controls

    The following figure shows the location of the on/off switch. ① On/off switch On/off button Note The on/off button is only effective when the power supply is switched on via the on/off switch at the rear of the device. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 16 Perform a hardware reset only in the case of an emergency. Close all running programs. Make sure that there is no more read or write access to drives and I/O before performing the hardware reset. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 17: Safety Instructions

    Siemens' products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customers' exposure to cyber threats.
  • Page 18: General Safety Instructions

    When you open the control cabinet, some areas or components might be carrying life- threatening voltages. If you touch these areas or components, electric shock might kill you. Switch off the power supply to the cabinet before opening it. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 19 When the device is used in the area of Industrial Control Equipment in accordance with UL61010-2-201, the device is classified as "Open equipment". Open equipment must be installed within an enclosure which protects you from hazards, including mechanical hazards, electrical shock and spread of fire. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 20 "Replacing the backup battery (Page 56)" in the operating instructions. • For any requirements on product maintenance, contact Siemens Technical support (Page 123). • Do not throw lithium batteries into fire, do not solder on the cell body, do not recharge, do not open, do not short-circuit, do not reverse polarity, do not heat above 100°C and...
  • Page 21: Headphones

    • If the device has an on/off button, assign the parameters of the function of the on/off button to meet your requirements under Windows. You can find the settings in the "Power Options" menu. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 22: Notes On Use

    E) Reliable Earthing - Reliable earthing of rack-mounted equipment should be maintained. Particular attention should be given to supply connections other than direct connections to the branch circuit (e. g. use of power strips). SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 23 A mains cable is not included with IPC347E. Make sure the cable you use provides a proper earth connection. It is highly recommended that you use a mains cable from SIEMENS. Note Use in an industrial environment without additional protective measures This device was designed for use in a normal industrial environment according to IEC 60721-3-3.
  • Page 24 Safety instructions 2.4 Notes on use SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 25: Installing And Connecting The Device

    Do not dispose of the original packaging. Pack the device when it needs to be transported or stored. 5. Inspect the contents of the packaging and all the accessories you ordered. Make sure that they are complete and not damaged. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 26: Device Identification Data

    The following illustrations are examples. The data of your device may differ from the data in these examples. Rating plate The rating plate is located on the inside of the front door for the SIMATIC IPC347E. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 27 Installing and connecting the device 3.1 Preparing for installation The rating plate of the SIMATIC IPC347E is shown below. Identification data Where is it? ① Order number ② Serial number ③ Product version ④ Unified Siemens address for product liability...
  • Page 28: Installing The Device

    Before you install the device, note the following general installation information. Note If the equipment is used in a manner not specified by the manufacture, the protection provided by the equipment might be impaired. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 29: Mounting Location And Position

    ● All the external circuit of the device must be SELV circuit. 3.2.2 Mounting location and position Optional mounting locations The device can be mounted horizontally in control desks and 19" rack systems. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 30 The device may fall down, injure people and get damaged. Secure the device using additional measures. The mounting screws of the telescopic rails may not protrude more than 5 mm into the device. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 31: Connecting The Device

    Regenerative feedback of voltage to ground by a connected or installed component destroys the device. Connected or built-in I/Os, for example, a USB drive, are not permitted to supply any voltage to the device. Regenerative feedback is generally not permitted. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 32: Connecting The Function Earth

    A mains cable is not included with IPC347E. Make sure the cable you use provides a proper earth connection. It is highly recommended that you use a mains cable from SIEMENS. 3.3.2 Connecting the function earth A connected function earth discharges electrical charges from the metal enclosure.
  • Page 33: Connecting The Power Supply

    • The permitted nominal voltage of the device must correspond to the local mains voltage. • Do not operate the device in non-grounded or impedance-grounded networks (IT networks). • Operate the device only in grounded power networks (TN networks in accordance with IEC 60364-1). SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 34 ● Type SJT with three conductors ● Conductor cross-section ≤ 18 AWG ● Cable length ≤ 4.5 m 220V supply voltage ● Type RVV with three conductors ● conductor cross-section ≤ 18 AWG ● Cable length ≤ 4.5 m SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 35: Connecting The Device To Networks

    Control level. Information on SIMATIC NET can be found on the SIMATIC NET Manual Collection CD. The software package and the documentation are not included in scope of the delivery. Additional information You can find additional information at the following link: Siemens central support (https://support.industry.siemens.com) SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 36: Dual-monitoring

    You can operate on up to two monitors with the VGA and DVI-D cables. The output on the extended monitor can be the same as the main monitor or the extension desktop of the main monitor. You can configure it in windows screen and display setting. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 37: Commissioning The Device

    The operating safety of the device and the plant is at risk. Do not switch off the device during the entire installation process. Do not change the default values in the BIOS setup. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 38: Switching Off The Device

    For non-Windows operating systems: ● Briefly press the on/off button. The operating system is shut down. The "POWER" LED goes out. The device is switched off but not fully disconnected from the mains voltage. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 39 Data on the drive may be lost. The device may be damaged. Perform a hardware reset only in the case of an emergency. For all operating systems: ● Press the on/off button for more than four seconds. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 40 Commissioning the device 4.3 Switching off the device SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 41: Installing Hardware Expansions

    Limitation of liability All technical specifications and approvals apply only to expansions which are approved by the Siemens AG. We are not liable for functional limitations caused by using a third-party devices or components. Observe the installation instructions for the components. UL approval of the device is valid only if UL-approved components are used in observance of their intended purpose ("Conditions of Acceptability").
  • Page 42: Expansion Cards

    (Page 73). Note The PCI card is limited to 5 V and universal board. The total power consumption of the modules is not permitted to exceed 75W in total. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 43: Installing Expansion Cards

    ● The device is disconnected from the mains. ● The device is open. Procedure 1. Remove the retaining screw and remove the card holder. 2. Remove the slot bracket of the slot for the expansion card. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 44 4. Secure the expansion card with the designated screw. ① ② 5. Loosen the bracket by unscrewing its screw and place it on the expansion card. 6. Secure the bracket. 7. Close the device. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 45: Disk Drives

    ● The device is disconnected from the mains. ● PH2 screwdriver Procedure 1. Unlock the front door and open the right-front door. 2. Remove the top cover. 3. Disconnect the power supply and data cables. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 46: Installing Drives Or Hard Disks

    The forth screw is behind the right handle. 5. Lift the drive cage completely out of the device. 5.3.3 Installing drives or hard disks Requirement ● The drive carrier has been removed. ● PH2 screwdriver SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 47 The screws to be installed on the right side of the slot are highlighted in the figure below. 4. Install the driver cage again. 5. Connect the power and data cables to the drive. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 48: Removing And Installing Internal Hard Disks

    Procedure for installing the hard disk drive ① Place the drive onto the drive bay plate and secure the drive with four screws SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 49: Device Maintenance

    Improper BIOS updating may result in irreparable motherboard damage. Only use the qualified tool from Siemens and follow the guideline when you need to update the BIOS. The warranty will be invalid if you update the BIOS with unqualified tool and damage the motherboard.
  • Page 50: Recycling And Disposal

    Recycling and disposal The devices described in these operating instructions can be recycled thanks to their low level of pollutants. Contact a certified disposal service company for environmentally sound recycling and disposal of your old devices. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 51: Maintenance

    5 years 3 years Filter mat Depending on the degree of soiling The filter can be reused after cleaning. 6.3.2 Replacing filters Requirement ● The device is disconnected from the mains. ● A filter mat SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 52: Beep Code

    6. Follow the steps for removing the filter in reverse order to install a new one. 6.3.3 Beep code Beep code Beeps Description 1 short beep Power on correctly 4 short beeps Memory error 5 short beeps Keyboard error SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 53: Removing And Installing Hardware Components

    Procedure - Installing the fan To install the fan, follow the steps for removing it in reverse order. During installation, make sure that the arrow on the fan points away from the fan bracket. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 54: Installing Memory Module

    • A memory module can be installed only when the direction is correct. Switch the direction if the memory cannot able to be inserted into the memory socket. • DDR2 and DDR3 memory modules are not compatible. Please make sure to install DDR3 Memory Module on this motherboard. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 55 2. Align a memory module on the socket so the notch on memory matches the alignment key on memory socket. 3. Insert and press the memory module into the socket until the retaining clips snap back to the original place, and the Memory Module is seated properly. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 56: Replacing The Backup Battery

    • Replace the battery every 5 years. • Replace the lithium battery only with the type recommended by the manufacturer. • For any requirements on product maintenance, contact Siemens Technical support (Page 123). • Do not throw lithium batteries into fire, do not solder on the cell body, do not recharge, do not open, do not short-circuit, do not reverse polarity, do not heat above 100°C and...
  • Page 57: Removing The Power Supply

    1. Disconnect the power supply cables of the drives and the motherboard. 2. Remove the cable ties securing the power cables in the housing. ① 3. Remove the retaining screws 4. Remove the power supply of the housing from the top. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 58: Removing The Motherboard

    ● A suitable processor Only an approved processor is permitted to be installed on the motherboard of the device. If the processor type is changed, the BIOS must be updated so that the suitable microcode is loaded. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 59 2. Remove the highlighted fan connector. 3. Remove the highlighted screws. The fourth screw is hidden by the heat sink in the figure. 4. Remove the heat sink. 5. Unlock the socket and lift the socket cover. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 60 Processor type and clock frequency If you use a processor of a different type, perform the BIOS update firstly. During the BIOS update, the microcode matching the processor is loaded. Contact the SIEMENS support to update the BIOS if you changed a different processor.
  • Page 61: Installing The Software

    ● Check whether you can retrieve your authorization or license key from the disk and perform this procedure if possible. ● If backup is not possible, please contact Customer Support. There you can obtain information necessary for software authorization. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 62 1. Insert the Restore DVD into the DVD drive. 2. Reboot the device. 3. Press the <F10> key and set CD/DVD as the priority 1 in the boot menu. 4. Reboot the device. 5. Click Next button to start the restoration. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 63 If "Format selected HardDisk" or "Restore Factory Settings" is set, all data, user settings, authorizations or license keys will be lost on the entire hard disk setting. 7. Click OK to reboot the device in prompt window after the restoring finished. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 64: Installing Windows

    After a few seconds, you will see the "Install Windows" installation program. For setting the boot sequence, refer to Boot Setup (Page 115). 7. Now follow the instructions in the installation program. You can find additional information on this in the section: "Install Windows" installation program. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 65 "Install Windows" installation program. The following dialog windows are then available: ● Example 1: Windows installation window Refresh Updating Drive options Integration of controller drivers unknown to the operating system and required for (advanced) installation. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 66 Information on how the data medium is partitioned in its delivery state is available in the tables below. 2. Select the partition on which you want to install the operating system. 3. Click "Next". Installation is started. The Windows operating system is installed on the data medium. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 67: Installing Drivers And Software

    5. Install the required driver. For more information on installing the drivers, see Installing the drivers on Windows 7 (Page 97). Note The driver for the chipset has to be installed before all other drivers with a new installation of Windows XP or Windows 7. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 68 Device maintenance 6.5 Installing the software SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 69: Technical Specifications

    ISO 9001 certificate The Siemens quality management system for our entire product creation process (development, production and sales) meets the requirements of ISO 9001:2008.This has been certified by DQS (the German society for the certification of quality management systems).
  • Page 70 CANADA Canadian notice This Class A digital apparatus complies with Canadian ICES-003. Avis Canadian Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 71 Technical specifications 7.1 Certificates and approvals Responsible party for Supplier's Declaration of Conformity Siemens Industry, Inc. Digital Factory - Factory Automation 5300 Triangle Parkway, Suite 100 Norcross, GA 30092 Mail to: (amps.automation@siemens.com) Australia and New Zealand This product meets requirements of EN IEC 61000-6-4:2011 Generic standard.
  • Page 72: Guidelines And Declarations

    This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Dimension drawings 7.3.1 Dimension drawing of the device Front view and plan view SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 73: Dimensional Drawings For The Installation Of Expansion Cards

    Technical specifications 7.3 Dimension drawings All dimensions are in mm. 7.3.2 Dimensional drawings for the installation of expansion cards Long PCI card, PCIe card SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 74: Dimension Drawing For The Use Of Telescopic Rails

    For detailed information on dimensions, refer to "Dimension draw- ing of the device (Page 72)". Weight 13.3 up to 17.0 kg; depending on the equipment Supply voltage (V 100 V AC to 240 V AC (-10%, +10%) SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 75 ± 2 kV (in accordance with IEC 61000-4-5; Surge, length > 30m) Immunity to discharges of static ± 4 kV, contact discharge (to IEC 61000-4-2) electricity ± 8 kV, atmospheric discharge (to IEC 61000-4-2) SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 76 , 6 ms, 1000 shocks per axis Special features Quality assurance In accordance with ISO 9001 Altitude of operation (m) Up to 2000 m Pollution Degree No burner operation At +5 °C to +35 °C without restrictions, even burner operation SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 77 DVD ROM: Single layer 16x, dual layer 12x • DVD-R/+R: 16x • DVD-RW/+RW: 12x • CD-ROM/CD-R: 48x, Finalized CD-RW: 40x • Write: DVD+/-R 24x, DVD+RW 8x, DVD-RW 6x, DVD+/-R9 (DL) • CD-R: 48x, CD-RW or plus: 24x • SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 78 1 x USB 2.0 vertical (500 mA) Ethernet 2 x Ethernet interface (RJ45) Wake on LAN, remote boot supported. 10/100/1000 Mbps Audio Realtek® ALC887, 5.1 channels, high definition audio codec. Micro • Line In • Line Out • SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 79: Power Requirements Of The Components (maximum Values)

    The total output of the +5 V and +3.3 V voltage must not exceed 130 W. The inrush current is: ● For 110 V AC: Maximum 70 A, 5 ms ● For 230 V AC: Maximum 140 A, 5 ms SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 80: Telescopic Rails

    Using a mains cable without proper earth connection can result in personal injury or even death by electric shock. A mains cable is not included with IPC347E. Make sure the cable you use provides a proper earth connection. It is highly recommended that you use a mains cable from SIEMENS. Plug type Region...
  • Page 81: Bios Description

    For a detailed description of how to call up and operate the BIOS setup and which menus and setting options are available, refer to the Appendix BIOS. CAUTION Risk of data lost After a BIOS update, all BIOS settings will restore to its original state. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 82 Technical specifications 7.5 BIOS description SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 83: Appendix Motherboard

    Use a grounding wrist strap at all times. Place all electronic components on a static‐dissipative surface or in a static‐shielded bag when th ey are not in the chassis. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 84: Jumpers

    To connect the pins, lid the pin with the clip. To disconnect a jumper, remove the clip. Some jumpers have three pins, labeled 1, 2 and 3. In this case you can connect either pins 1 and 2 or 2 and 3. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 85 Clear COMS (CLRTC1) NOTICE Move the jumper back to protected mode after clearing CMOS. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 86 Appendix Motherboard A.2 Jumpers COM2 +5V/+12V Selection (COM2_V1) SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 87: Internal Connector

    Appendix Motherboard A.3 Internal Connector Internal Connector A.3.1 Fan connector The pin assignment in the table below applies to all fan connectors on motherboard. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 88: Front Panel Connector (f_panel1 & F_panel2)

    A.3 Internal Connector A.3.2 Front panel connector (F_Panel1 & F_Panel2) The front panel connector is used to connect cable to Chassis Front Panel, and provide HDD LED, Power LED, Power Button and Reset Button functions. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 89: Internal Usb 2.0 Connector (usb 2_56 & Usb 2_78)

    Appendix Motherboard A.3 Internal Connector A.3.3 Internal USB 2.0 connector (USB 2_56 & USB 2_78) Internal USB 2.0 Connectors provides 4 USB 2.0 Ports which require appropriate cable to support. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 90: Internal Rs-232 Com Connector (com3 & Com4)

    Appendix Motherboard A.3 Internal Connector A.3.4 Internal RS-232 COM Connector (COM3 & COM4) Internal COM Connectors provides 2 RS-232 Ports which require appropriate cable to support. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 91: Internal Dio Connector (dio1)

    Appendix Motherboard A.3 Internal Connector A.3.5 Internal DIO Connector (DIO1) Internal DIO Connector provides 4-input and 4-output which require appropriate cable to support. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 92: Internal Lpt Connector (lpt1 - Parallel Port)

    Appendix Motherboard A.3 Internal Connector A.3.6 Internal LPT Connector (LPT1 – Parallel Port) Internal LPT Connectors provides parallel port interface which require appropriate cable to support. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 93: Internal Usb 2.0 Vertical Connector (usb2_9)

    Appendix Motherboard A.3 Internal Connector A.3.7 Internal USB 2.0 Vertical Connector (USB2_9) Internal USB 2.0 Vertical Connectors provides 1 Type-A USB 2.0 Port. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 94: Atx Power 24-pin Connector (eatx_pwr1)

    ATX Power 24‐Pin connector is for ATX PSU plug. Make sure you insert the ATX PSU plug on motherboard in the right orientation, otherwise the plug cannot be inserted. Note ATX Power 4‐Pin connector must be connected, otherwise the system cannot be turned on. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 95: Atx Power 4-pin Connector (eatx_pwr2)

    (Page 58) for detailed information. A.3.11 DDR3 Memory sockets The motherboard provides two memory sockets, which support two pieces of 240‐pin DDR3 Memory Modules. Refer to the chapter Installing memory module (Page 54) for detailed installation instruction. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 96: Sata 3.0/6.0 Gbps Port Connectors (sata6g_1/ Sata6g_2/ Sata3g_3/ Sata3g_4)

    The motherboard provides four pieces of 7‐pin SATA Port Connectors, which support SATA devices through the connection of SATA Cable. A.3.13 Battery socket The Battery Socket on the motherboard is for CR2032 Battery used for COMS data retention.. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 97: Installing Drivers

    6. Click Accept to accept License Agreement. Readme File Information 7. Click Install to confirm the and move on. 8. Click Restart Now or Restart Later to restart the computer for the changes to take effect. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 98 3. Click Run to allow the system to start the installation. 4. Click Yes to continue the installation. 5. Check the radio button next to “Yes, I want to restart my computer now.” and click OK to finish setup. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 99 4. Click Install to start the driver installation. 5. Click Finish to confirm the installation. 6. Check the radio button next to “Yes, I want to restart this computer now.” and click Finish to reboot the computer. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 100 Appendix Motherboard A.4 Installing drivers SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 101: Appendix Bios

    1. Power on the motherboard. 2. Press DELETE or ESC key on your keyboard during the Power - On - Self - Test (POST) when the SIEMENS logo is shown on screen. The Aptio TSE main BIOS setup menu is displayed.
  • Page 102: Main Setup

    You can press <Enter> Key to discard changes and exit. Or use arrow keys to select “No” then press <Enter> Key to abort this function and return to previous screen. Main setup The main setup menu The main setup menu is shown as below. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 103 Access level shows what access right you have to setup BIOS. For setting the access level, go to the chapter Security Menu. Access right Description Administrator Have full access right to change BIOS settings. User Have guest level access right and can only change limited items. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 104: Advanced Setup

    Follow the below instructions to enable system wake on alarm event at a specific time. 1. Select the Wake system with Fixed Time with the arrow keys and press Enter key. 2. Select Enabled and press Enter key in the active window pop-up. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 105 Description Suspend Disabled When the power button is pressed, the system disable the ACPI function. S3 only (Suspend to RAM) When the power button is pressed, the system enters S3 only (Suspend to RAM). SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 106 For Quad core CPU, you can select to enable All/1/2/3 cores as you need. But for dual-core CPU, you can only select All or 1. SATA configuration In SATA configuration page, you can view and configure SATA device. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 107 Description Auto This option disables Legacy USB Support if there is no USB device is connected. Enabled This option enables Legacy USB Support. Disabled This option keeps USB device available only for EFI application. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 108 2. Select Enabled or Disabled as you need and press Enter key in the active window pop- 3. The enabled port can select corresponding Change Setting and Device Mode and press Enter key. 4. Press F4 key and save the change. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 109 To enable RS-485 mode for serial port 1/2. For RS-422 and RS-485 mode, you can select high speed mode or normal mode. For RS-232 mode, only normal mode in the table below is available. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 110 Show the chassis fan1 speed. CHA Fan2 speed Show the chassis fan2 speed. +12V Show +12V power voltage. Show +5V power voltage. CPU VCORE Show VCORE power voltage. VSB3 Show VSB3 power voltage. VBAT Show VBAT power voltage. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 111: Chipset Setup

    Select Chipset from the BIOS setup page to enter the Chipset BIOS setup page. The Chipset page is shown as below. System agent configuration In system agent configuration page, you can view and configure system agent parameters. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 112 DVMT Total Gfx Mem. Use arrow keys to select mode you want, then press Enter key to active it. Option Description DVMT Pre-Allocated 32M, 64M, 96M, ..., 1024M Set DVMT 5.0 Pre-Allocated (Fixed) Graphics Memory size used by the Internal Graphics Device to a specific size. DVMT Total Gfx Mem SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 113 3. Press F4 key and save the change. See the options for power mode setting below: Option Description ATX Type Set Power mode to ATX type. ATX type is set as default. AT Type Set Power mode to AT type. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 114 1. Select ERP/EUP mode with the arrow keys and press Enter key. 2. Select Enabled or Disabled as you need and press Enter key in the active window pop- 3. Press F4 key and save the change. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 115: Boot Setup

    Disabled Set the motherboard to display the POST message. Enabled Set the motherboard to display the SIEMENS logo. This is the default set- ting for Quiet boot. Note If quiet boot function is set as Enabled in BIOS, you can press TAB key to switch to POST message when the IPC is booting.
  • Page 116 You can change the priority as similar to the main boot option priorities. The 1st boot option has the highest boot priority and ap- pears at the boot option priorities and boot order. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 117: Security Setup

    After the passwords are set, you must enter a password every time when you enter BIOS. Select Security menu item in BIOS Setup screen to enter Security setup screen. Security menu is shown below: SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 118 3. Re-enter the password when you are asked to confirm the password in the screen popped up. Note Record the new password when the password is changed. If you forget the password, you must erase the system configuration information in NVRAM. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 119: Save And Exit

    You can restore the system with the following instructions. 1. Select Restore Defaults with the arrow keys and press Enter key. 2. Select Yes and press Enter key to the load optimized defaults. Or Select No to quit. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 120 All the available boot options are listed below the Boot Override. You can select any of the options to boot from a particular device. Launch EFI shell from file system device Select EFI files for launching. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 121: Appendix The Pin Definition Of Atx Power Supply Output Connector

    Appendix The pin definition of ATX power supply output connector ATX power supply can convert the AC 220 V power to the DC 3.3 V, 5 V or 12 V power which are can be used in the internal computer. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 122 Appendix The pin definition of ATX power supply output connector SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 123: Appendix Technical Support

    ● Installed additional software Tools & downloads Please check regularly if updates and hotfixes are available for download to your device. The downloads are available on the Internet under "After Sales Information System SIMATIC PC/PG" (see above). SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 124: Problem Solving

    If you use an adapter or extension for the mouse • cable, also check these connectors. If the mouse pointer still does not appear on the screen after you have performed these checks and actions, contact your technical support team. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 125 After you change the SATA mode, you must boot the during Windows 10 reboot you installing the operating system. computer in the safe mode from Windows 10 once. Then you can boot in the normal Windows mode without blue screens. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 126 Appendix Technical support D.2 Problem solving SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 127: Appendix List Of Abbreviations

    Memory chip with high-speed interface Digital Versatile Disk Digital versatile disk Digital Visual Interface Digital display interface DVI-D Digital Visual Interface Digital display interface with digital sig- nals Error checking and correction Error correction code SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 128 Micro Memory Card Memory card of the format 32 mm x 24.5 Multipoint-capable interface for programming devices MS-DOS Microsoft Disc Operating System MTBF Mean Time Between Failures Multilanguage User Interface Language localization in Windows Not Applicable SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 129 Bi-directional bus system designed for up to 32 nodes Real Time Clock Real-time clock Reliable Transfer Service Request to send Receive Data Data transfer signal SATA Serial Advanced Technology Attachment SCSI Small Computer System Interface SDRAM Synchronous DRAM SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 130 ITU-T standardized recommendation for data transfer via serial ports Positive supply voltage of integrated circuits Verein deutscher Elektrotechniker (Union of German Electrical Engineers) Video Graphics Array Video adapter which meets industrial standard Voltage Regulator Module SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 131 Program monitoring with error detection and alarming WLAN Wireless LAN Wireless local area network Wake on Local Area Network World Wide Web Execute Disable Capability Hardware implementation Extended Graphics Array Graphic standard, maximum resolution 1024x768 pixels SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 132 Appendix List of abbreviations SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 133: Glossary

    2 x 2 sequences. Boot disk A boot disk is a disk with a "Boot" sector. This can be used to load the operating system from the disk. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 134 . This is done either by copying the configuration files supplied with the module or by manual configuration using the configuration utility. Controller Integrated hardware and software controllers that control the functions of certain internal or peripheral devices (for example, the keyboard controller). SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 135 RW "Rewritable" means you can rewrite the DVD up to approximately 1000 times. Error checking and correction is a method for detecting and correcting errors when saving and transferring data, frequently used in conjunction with RAM modules with and without ECC. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 136 EFI is located logically beneath the operating system and represents the successor to PC BIOS, focusing on 64-bit systems. File Based Write Filter (FBWF) Configurable write filter to protect individual files from write access. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 137 Integrated Graphics Device. Graphics interface integrated in the chipset. Image This refers to the image, for example, of hard disk partitions saved to a file in order to restore them when necessary. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 138 Legacy Boot Device Conventional drives can be used as USB devices. Legacy USB support Support of USB devices (e.g. mouse, keyboard) on the USB ports without driver. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 139 Glossary License key The license key represents the electronic license stamp of a license. Siemens provides the license keys for protected software. License key disk The license key disk contains the authorizations or license keys required to enable protected SIMATIC software.
  • Page 140 PC expansion cards in order to provide basic technologies to the market. PEG interface PCI Express for Graphics. Graphics interface with 16 PCIe lanes for expansions with graphics modules. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 141 PXE server A Preboot Execution Environment server is part of a network environment and can provide software to connected computers even before they boot. This can involve operating system installations or servicing tools, for example. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 142 It makes for permanent monitoring of important parameters and early detection of imminent problems. SATA Serial ATA Interface for hard disk drives and optical drives with serial data transmission rates of up to 300 Mbps. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 143 Turbo Mode In this mode individual processor cores can be clocked higher in accordance with the load from the user programs and as required. It is only supported by Core i5 and Core i7 processors. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 144 The CTRL+ ALT+ DEL hotkey can be used to initiate a warm restart. WLAN Wireless LAN is a local network that transmits data via radio waves, infrared light or another wireless technology. Wireless LAN is mainly used for mobile computer applications in office or factory environments. SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 145: Index

    Making known to the operating system, 65 Data exchange, 35 Degree of protection, 75 Device configuration, 81 Drive bay plate, 48 Korea, 71 Dust protection, 75 License key, 63 EAC, 71 Lithium battery, 56 SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 146 Plan view, 72 Supply voltage, 74 Power consumption, 75 Switching off the device Power requirements, 79 Disconnect from mains voltage, 39 Power supply Shutting down the operating system, 38 AC voltage, 79 System partition, 63 SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 147 Index Technical specifications, 74 Telescopic rails, 80 Tools, 50 UL approval, 70 Vent slots, 29 Warranty, 19 Windows 7 Installation, 64 Windows Server 2008 Installation, 64 Windows Server2008 R2 Installation, 64 SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...
  • Page 148 Index SIMATIC IPC347E Operating Instructions, 09/2018, A5E41134132-AE...

Comments to this Manuals

Symbols: 0
Latest comments:
