SIMATIC IPC PX-32A
SIMATIC
Industrial PC
SIMATIC IPC PX-32A
Operating Instructions
09/2023
A5E53092695-AA
Preface
Product description
Safety instructions
Installing and connecting
the device
Commissioning the device
Operating the device
Expanding and assigning
parameters to the device
Device maintenance and
repair
Technical specifications
Dimension drawings
Standards and approvals
Hardware description
Technical support
Markings and symbols
List of abbreviations
1
2
3
4
5
6
7
8
9
10
A
B
C
D

Advertisement

Table of Contents
loading

Related Manuals for Siemens SIMATIC IPC PX-32A

Summary of Contents for Siemens SIMATIC IPC PX-32A

  • Page 1 SIMATIC IPC PX-32A Preface Product description SIMATIC Safety instructions Installing and connecting the device Industrial PC SIMATIC IPC PX-32A Commissioning the device Operating the device Operating Instructions Expanding and assigning parameters to the device Device maintenance and repair Technical specifications...
  • Page 2 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 3: Preface

    General knowledge in the field automation control engineering is recommended. Scope of the operating instructions These operating instructions are valid for all order variants of the SIMATIC IPC PX-32A. History The following editions of these operating instructions have already been published:...
  • Page 4 Siemens' products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply latest updates may increase customers' exposure to cyber threats.

  • Page 5: Table Of Contents

    Connecting the device ....................... 36 3.3.1 Connecting the protective conductor ................. 36 3.3.2 Connecting the power supply ..................... 37 3.3.2.1 Connecting the terminal ....................37 3.3.2.2 Connecting the 9-36 V DC power supply ................39 SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...
  • Page 6 Current/power requirements and power supply ..............65 8.3.1 Current and power requirements of the system components ..........65 8.3.2 Technical specifications DC power supply (DC) ..............66 Electromagnetic compatibility .................... 66 Ambient conditions......................67 SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...
  • Page 7 I/O address allocation ......................85 A.4.2.1 Overview of the internal module registers ................85 A.4.2.2 Battery status register (read only) ..................86 A.4.2.3 Watchdog timer (WDT) register (read/write) ............... 87 A.4.2.4 NVRAM address register ..................... 88 SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...
  • Page 8 Markings and symbols ......................... 92 Overview ........................... 92 Safety ..........................92 Operator controls....................... 92 Certificates, approvals and markings .................. 93 Interfaces .......................... 94 List of abbreviations ..........................95 Abbreviations ........................95 Index ..............................97 SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 9: Product Description

    • Boot modes Windows® operating Information on: • Online at: system • Commissioning the operating Microsoft® Windows® 10 system (https://support.industry.siemens. • Restoring the operating system com/cs/ww/en/view/109749498) • Configuration of the operating system SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...
  • Page 10 Information on: • Online at: bootable USB flash SIMATIC IPC Creating a bootable • Creating a bootable USB flash drive USB flash drive drive for recovery of operating (https://support.industry.siemens. system, software and drivers com/cs/ww/en/view/109811224) SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 11: Product Highlights

    Product description 1.2 Product highlights Product highlights The SIMATIC IPC PX-32A with innovative Intel processor architecture is a cost-optimized industrial panel PC that supplements the Embedded series. It is a cost- and function-reduced alternative to SIMATIC IPC PX-39A. Device view...

  • Page 12: Applications

    • Process and visualization applications • Industrial image processing • Quality assurance and monitoring tasks • Measurement, control and rule-based tasks • Data acquisition and management SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 13: External Design Of The Device

    Position for the fixing screws of the strain relief ⑩ 2 × Ethernet Connections for Ethernet RJ45 for 10/100/1000 Mbps X1 P1/X2 P1 • Ethernet X1 P1 is iAMT-capable • Ethernet X2 P1 SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 14: Status Displays

    Slot for memory module ② Motherboard ③ Backup battery ④ Heat sink for drive (SSD) ⑤ Slot for drive (SSD) under the heat sink ⑥ Slot for M.2 expansion module ⑦ Power supply 9-36 V DC SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 15: Accessories And Spare Parts

    Accessories and spare parts 1.6.1 Hardware accessories Accessories from Siemens are available for your device that are not included in the scope of delivery. Obtaining accessories from the SIEMENS Industry Mall 1. On the Internet, go to Industry Mall (https://mall.industry.siemens.com).

  • Page 16: Safety Instructions

    • Disconnect the device from the power supply in good time when a thunderstorm is approaching. • Do not touch power cables and data transmission cables during a thunderstorm. • Keep sufficient distance from electric cables, distributors, systems, etc. SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...
  • Page 17 It is therefore inevitable that the display will contain a small number of defective pixels. This does not limit the function in any way provided the defective pixels are not all in one location. SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...
  • Page 18 The device contains electronic components which may be destroyed by electrostatic charge. This can result in malfunctions and damage to the machine or plant. Take corresponding precautionary measures before you open the device. SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 19: Note On Transport And Storage

    • Do not expose the device to direct heat radiation from a heating device. • If condensation develops, wait approximately 12 hours or until the device is completely dry before switching it on. SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 20: Notes On Mounting

    • Please note that when the device is operated in severe environments which are subject to caustic vapors or gases, the provision of clean air is ensured. • Clean the enclosure surface with a damp cloth and make sure that no water enters the device. SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...
  • Page 21 • Switch off radiating devices. • Reduce the radio output of radiating devices. • Read the information on electromagnetic compatibility. • Read the information in the technical specifications. See also Ambient conditions (Page 67) SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 22: Information On I/O Devices

    • The IPC in question must be turned off and the power supply connector must be plugged • During the measurement, all cables from the plant to the IPC should be connected. • All other components in the plant must be active. SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 23: Notes On The Touch Screen

    Do not touch the screen in the following situations: • During the boot process • When plugging or unplugging USB components • While Scandisk is running • During a BIOS update SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 24: Notes On Device And System Extensions

    • UL approval of the device only applies when the UL-approved components are used according to their "Conditions of Acceptability". • We are not liable for functional limitations caused by the use of third-party devices or components. SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 25: Installing And Connecting The Device

    You will find the latest information on additional software for your device under: Accessories and spare parts (Page 15) Printed documents • Quick Install Guide SIMATIC IPC PX-32A • Product Information "Important notes on your device" SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 26: Checking The Delivery Package

    If the contents of the package are incomplete, damaged or do not correspond to your order, you can use the After Sales Information System (ASIS) (http://siemens.com/asis) to provide feedback on product deliveries and repairs. Complete the online form for product delivery (quality control notification) under the heading "Product delivery: Feedback on quality control and repairs".

  • Page 27: Identification Data Of The Device

    The following illustrations are examples. The data of your device may differ from the data in these examples. Nameplate The following image shows the nameplate on the SIMATIC IPC PX-32A as an example. COA label The COA label (Certificate of Authenticity) is located on the side of the device.

  • Page 28: Mounting Positions

    "Ambient conditions (Page 67)". Mounting in horizontal format Vertical mounting in horizontal format or inclined mounting in horizontal format with vertical inclination of max. ±45°: For temperature specifications, see section "Ambient conditions (Page 67)". SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 29: Preparing The Mounting Cutout

    • Permissible deviation from plane at the mounting cutout: ≤ 0.5 mm This condition must be fulfilled for the mounted HMI device. • Permissible surface roughness in the area of the mounting seal: ≤ 120 µm (R 120) SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...
  • Page 30 19" 22" Width w Height h Width and height must be interchanged for mounting in vertical format. Installation depth Information on the overall depth is available in the section "Dimension drawings (Page 71)". SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 31: Installing The Device

    • Ensure there is enough clearance in the control cabinet to allow the backplane cover to be removed. • Equip the control cabinet with struts for stabilizing the mounting cut-out. Install struts where necessary. See also Mounting positions (Page 28) SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 32: Mounting The Device With Mounting Clips

    If the mounting seal is damaged or protrudes from the device, the guaranteed degree of protection is not ensured. It is prohibited from mounting the device if the mounting seal is damaged. 1. Working from the front, insert the device into the mounting cut-out. SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...
  • Page 33 Fasten the mounting clips to the positions as illustrated. The number of mounting clips depends on the device: 22" (12 x), 19" (12 x), 15" (10 x), 12" (9 x) Device Position 22" display 19" display SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 34: Fastening A Device Using A Vesa Adapter

    3.2.3 Fastening a device using a VESA adapter You can also fasten the SIMATIC IPC PX-32A up to a display size of 24" using a 100 x 100 mm VESA adapter. Different models of VESA adapters are offered by third-party manufacturers.
  • Page 35 Procedure 1. Attach the VESA adapter 100 x 100 mm to the marked locations. 2. To do this, use M4x10 screws with property class 8.8 and tighten these with a torque of 3 SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 36: Connecting The Device

    2. Screw the cable lug onto the protective conductor connection as shown. 3. Wire the protective conductor to the protective conductor connection of the control cabi- net in which the device is installed. SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 37: Connecting The Power Supply

    Utilisez des câbles en cuivre (Cu) pour tous les câbles d'alimentation qui sont raccordés à l'appareil par des bornes, par exemple les câbles d'alimentation 24 V CC sur le connecteur d'alimentation 24 V CC. SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...
  • Page 38 Installing and connecting the device 3.3 Connecting the device 1. Connect the cables as shown with a tightening torque of 0.6 Nm. Make sure the connection terminal is in the correct position as shown. SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 39: Connecting The 9-36 V Dc Power Supply

    The 9-36 V DC power supply features reverse polarity protection. If you mix up the 9-36 V DC connecting cables and ground, the device is not damaged but does not switch on. After the power supply has been connected correctly, the device will again be ready to operate. SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 40: Connecting I/O Devices

    1. Connect the I/O devices to the respective interfaces. Information on the position of the interfaces is available in "Interfaces and operating elements (Page 13)". 2. Secure the cables with the strain relief. See: Securing the lines (Page 42) SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 41: Connecting The Device To Networks

    Control level. You can find information on this under SIMATIC NET (http://w3.siemens.com/mcms/automation/en/industrial- communications/Pages/Default.aspx). The software package and the documentation are not included in the scope of delivery. Additional information You can find additional information on the Internet at: Technical Support (https://support.industry.siemens.com). SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 42: Securing The Lines

    2. Pass the cable tie around the strain relief bar and secure the cables as shown. 3. Cut off the protruding ends of the cable ties. SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 43: Commissioning The Device

    Switching off the device Shutting down the operating system For active operating system • Shut down the operating system properly. Result The device is switched off but not fully disconnected from the line voltage. SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...
  • Page 44 Perform a hardware reset only in the case of an emergency. • Operate the on/off switch to initiate a hardware reset, see "Interfaces and operating elements (Page 13)". See also General safety instructions (Page 16) SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 45: Operating The Device

    • While Scandisk is running • During a BIOS update • Screen keyboard for touch device • External keyboard, connected via USB • External mouse, connected via USB See also Notes on the touch screen (Page 23) SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 46: Trusted Platform Module (Tpm)

    Activate the Trusted Platform Module You can find information on activating the Trusted Platform Module in the detailed firmware/BIOS description, see "Important instructions and manuals for operating the device (Page 9)". SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 47: Expanding And Assigning Parameters To The Device

    The device contains electronic components which may be destroyed by electrostatic charge. This can result in malfunctions and damage to the machine or plant. Take corresponding precautionary measures before you open the device. SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...
  • Page 48 2. Tilt the PC enclosure away from the touch panel. 3. Disconnect the three marked cables from the motherboard. Note: The gold-colored, right foil cable must be unlocked beforehand. 4. Put down the front panel. Close the device in reverse order. SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 49: Expansion Modules (M.2)

    • The connecting cable between M.2 modules and conditioner card should be at least 150 mm long. See also Position of the interfaces on the motherboard (Page 82) Dimension drawing of expansion modules (M.2) (Page 75) SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 50: Installing/Removing Expansion Modules (M.2)

    Torx T8. Insert the M.2 module into the relevant slot (X100). Take care not to touch the contacts of the M.2 module when you do this. SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...
  • Page 51 You may need to make settings in the BIOS Setup. For detailed information about installation, please refer to the documentation provided with the specific expansion module. See also Replacing M.2 NVMe SSD (Page 54) SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 52: Memory Modules

    • DIMM DDR4 memory modules • Memory transaction rate 3200 MT/sec "unbuffered" • "without ECC" Note Use only the memory modules recommended by Siemens AG. Requirement • The device is open, see important information under "Opening the device (Page 47)". Procedure - Removal 1.
  • Page 53 After insertion and removal Close the device. The new memory capacity will be automatically detected and displayed in the BIOS setup when the device is switched on. SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 54: Drives

    • Screwdrivers of type Torx T10 and T8 Procedure - Removal Remove the designated screws of the heat sink with the type Torx T10 screw- driver. Remove the heat sink upwards and set it aside. SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...
  • Page 55 Torx T8. 4. Pull the M.2 NVMe SSD out of the slot. Procedure - Installation Follow the steps for removal in reverse order. See also Hardware accessories (Page 15) SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 56: Device Maintenance And Repair

    Replacement interval Backup battery 5 years Depending on the type of use The interval for replacement of the flash drives (SSD) depends greatly on the type of use. A specific interval cannot be given. SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 57: Cleaning The Device Front

    • See the notes under "Notes on ambient and environmental conditions (Page 20)". Cleaning the Device Front 1. Switch off the device. 2. Dampen the cleaning cloth. 3. Clean the device with the cleaning cloth. SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 58: Removing And Installing Hardware

    100 °C and make sure to protect the battery from direct sunlight, moisture and condensation. SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...
  • Page 59 (Page 9). • The device is open, see important information regarding this under Opening the Device (Page 47). • You have observed the local regulations relating to the disposal of used batteries. SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...
  • Page 60 2. Place the new battery below the two con- tacts (1) and press it into the base (2) while applying slight pressure. 3. Close the device. 4. Check the firmware/BIOS settings. See also Maintenance intervals (Page 56) SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 61: Installing Operating System, Software And Drivers

    Installing operating system, software and drivers You can restore the factory settings of the target system (i.e. the volume partitions, the operating system with installed device drivers, and the SIEMENS software products). This allows you to restore your device quickly if it has suffered damage.

  • Page 62: Backing Up Data And Changing Partitions

    Contact a certified disposal service company for electronic scrap for environmentally sound recycling and disposal of your old device, and dispose of it according to the relevant regulations in your country. SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 63: Technical Specifications

    77 W (at 36 V) Noise emission < 40 dB(A) according to DIN 45635-1 Degree of protection IP 20 according to IEC 60529 IP 65 (front) Quality assurance In accordance with ISO 9001 SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...
  • Page 64 • IEC 61010-2-201 • EN 61010-2-201 • DIN EN 61010-2-201 • UL 61010-2-201 • CSA C22.2 No 61010-2-201 not evaluated by UL See also Connecting the 9-36 V DC power supply (Page 39) SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 65: Current/Power Requirements And Power Supply

    Device with BIOS setting "Power & 3.88 A 46.56 W 1.93 A 46.32 W Performance Scenario" = "Balanced" Device with BIOS setting "Power & 4.20 A 50.40 W 2.14 A 51.36 W Performance Scenario" = "Max Per- formance" SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 66: Technical Specifications Dc Power Supply (Dc)

    10 V/m 80 MHz – 2.7 GHz, 80% AM to IEC 61000-4-3 • 3 V/m 2.7 – 6 GHz, 80% AM to IEC 61000-4-3 • 10 V 10 kHz – 80 MHz, 80% AM according to IEC 61000-4-6 SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 67: Ambient Conditions

    5 °C for the setting "Max Performance". Technical specifications of the drives See the note in "Applicability of technical specifications (Page 63)". M.2 NVMe SSD >= 256 GB, form factor 22 mm x 30 mm, type M SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 68: Technical Specifications Of The Motherboard

    MTBF: Operating hours after which the maximum brightness is reduced by half compared to the original value. MTBF is increased by using the integrated dimming function, for example, time- controlled via screen saver or centrally via PROFIenergy. SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 69: Technical Specifications Of The Interfaces

    No teaming with iAMT When using iAMT, the X1 P1 interface must be used to connect to remote maintenance. Only possible with ports X1 P1 and X2 P1 SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 70: Technical Specifications Of The Operating Systems

    The following table lists the partitioning for disks ≥ 200 GB in GPT mode: Partition Name Size File system First Boot 260 MB FAT32 Second 128 MB None Third System 160 GB NTFS Fourth WinRE 500 MB NTFS Fifth Data Remainder NTFS SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 71: Dimension Drawings

    Dimension drawings Dimension drawing of 12" device with resistive single-touch screen SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 72: Dimension Drawing Of 15" Device With Resistive Single-Touch Screen

    Dimension drawings 9.2 Dimension drawing of 15" device with resistive single-touch screen Dimension drawing of 15" device with resistive single-touch screen SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 73: Dimension Drawing Of 19" Device With Resistive Single-Touch Screen

    Dimension drawings 9.3 Dimension drawing of 19" device with resistive single-touch screen Dimension drawing of 19" device with resistive single-touch screen SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 74: Dimension Drawing Of 22" Device With Resistive Single-Touch Screen

    Dimension drawings 9.4 Dimension drawing of 22" device with resistive single-touch screen Dimension drawing of 22" device with resistive single-touch screen SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 75: Dimension Drawing Of Expansion Modules (M.2)

    Dimension drawings 9.5 Dimension drawing of expansion modules (M.2) Dimension drawing of expansion modules (M.2) Maximum dimensions of expansion modules Dimension drawing of the conditioner card SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 76: Standards And Approvals

    • 2011/65/EU "Restriction of the use of certain hazardous substances in electrical and electronic equipment" (RoHS Directive) EU Declaration of Conformity The associated declaration of conformity is available on the Internet at the following address: Panel PC certificates (http://support.automation.siemens.com/WW/view/en/10805572/134200). SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 77: Ukca Marking

    DIN ISO 9001 certificate and software license agreements ISO 9001 certificate The Siemens quality management system for our entire product creation process (development, production and sales) meets the requirements of ISO 9001. This has been certified by DQS (the German society for the certification of quality management systems).

  • Page 78: Fcc (Usa)

    10.7 Canada CANADA Canadian Notice This Class A digital apparatus complies with Canadian ICES-003. Avis Canadien Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Ca- nada. SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 79: Australia / New Zealand

    This product meets the requirements of Korean certification. This product satisfies the requirement of the Korean Certification (KC Mark). 이 기기는 업무용(A급) 전자파 적합기기로서 판매자 또는 사용자는 이 점을 주의하시기 바라며 가정 외의 지역에서 사용하는 것을 목적으로 합니다. SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 80: Taiwan

    Note 3：The "−" indicates that the restricted substance corresponds to the exemption. 電池和蓄電池 WARNING 警告 — 置換可能影響安全防護的錯誤型式的電池（例：在某些鋰電池類型的情形下）； — 電池丢入火焰或烤箱中，或將電池作可能導致爆炸的機械擠壓或切割； — 電池置於可能導致爆炸或可燃性液體或氣體洩漏的高溫環境中；且 — 電池承受可能導致爆炸或可燃性液體或氣體洩漏的極度低氣壓。 Responsible party for Supplier's Decalation of Conformity / 供應商符合性聲明的責任方 西門子股份有限公司 臺北市11503南港區園區街3號8樓 電子郵件信箱：Adscs.taiwan@siemens.com SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 81: Hardware Description

    Slot for expansion modules (M.2) ④ Backup battery ⑤ Slot for the bus board Technical features of the motherboard Technical features of the motherboard can be found under "Technical specifications of the motherboard (Page 68)". SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 82: Position Of The Interfaces On The Motherboard

    (6) COM4 (X33) (10) USB 2.0 (X64 Internal 1) (3) 2 × Ethernet (7) COM3 (X32) (11) Power supply (X10) (X1 P1 iAMT-capable/X2 (4) COM1 (X30) (8) Interface for M.2 NVMe SSD (X101) SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 83: Internal Interfaces

    Internal M.2 Key B, assigned PCIe bus signals Port for SSD drive bay Internal Socket for SSD drive bay, assigned PCIe bus signals A.2.2 USB ports Designation VBUS_USB1 VBUS_USB2 USB1_D- USB2_D- USB1_D+ USB2_D+ SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 84: External Interfaces

    USB 3.2 X60, X61 USB 3.2 Gen 2 socket type A X62, X63 Ethernet 1, 2, 3 X1 P1, RJ45 and 4 X2 P1, X3 P1, X4 P1 X70, X71 20-pin DisplayPort connector SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 85: System Resources

    WDT counter register Base address + offset 7 WDT status register The following tables describe the system resources for the factory state of the device. See also Watchdog timer (WDT) register (read/write) (Page 87) SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 86: Battery Status Register (Read Only)

    Reserved Reserved Reserved CMOS battery capacity is still sufficient CMOS battery capacity is exhausted (remain- ing capacity is still sufficient for approx. 1 month) CMOS battery is empty or missing Reserved Reserved Reserved SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 87: Watchdog Timer (Wdt) Register (Read/Write)

    This step resets the "PC ON/WD" LED from pulsing red to its normal state (lit green). The WDT starts counting down. To prevent this behavior, stop the WDT before resetting the status to "Active". SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 88: Nvram Address Register

    NVRAM address register PCI register address: PCI register content: Length of the memory area NVRAM base address register NVRAM memory address (default) E300 0000 Address is assigned dynamically (de- 80000 h pending on device configuration) SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 89: Technical Support

    You can find additional information and support for the products described on the Internet at the following addresses: • Technical support (https://support.industry.siemens.com) • Support request form (https://www.siemens.com/supportrequest) • After-sales information system for SIMATIC PC / PG (https://www.siemens.com/asis) • SIMATIC Documentation Collection (https://www.siemens.com/simatic-tech-doku-portal) • Your local representative (https://www.automation.siemens.com/aspa_app) • Training center (https://siemens.com/sitrain) •...

  • Page 90: Troubleshooting

    If you use an adapter or expansion for the mouse cable, also check these connectors. If the cursor still does not appear on the screen after you have performed these checks and actions, con- tact your technical support team. SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 91: Problems When Booting The Device

    "Boot > EFI". firmware/BIOS The boot data carrier is set up with Enable UEFI mode in the firmware/BIOS. GPT and UEFI boot is deactivated in the firmware/BIOS SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 92: Markings And Symbols

    Disconnect the power plug before Opening for Kensington lock opening Attention ESD (Electrostatic sensitive Warning of hot surface device) Operator controls Symbol Meaning Symbol Meaning On/off switch, without electrical isola- On/off switch, without electrical isola- tion tion SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 93: Certificates, Approvals And Markings

    EFUP (Environment Friendly Use Peri- Approved for Korea od) marking for China Test mark of the Underwriters Labora- UKCA marking for Great Britain tories Approval for India Disposal information, observe the local regulations. Approval for Taiwan SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 94: Interfaces

    LAN interface, not approved for con- Line Out necting WAN or telephone Serial port Microphone input USB port Universal Audio Jack USB 2.0 high-speed port Headphone output USB 3.0 super-speed port USB 3.1 SuperSpeedPlus interface SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 95: List Of Abbreviations

    Digital display interface with digital and VGA signals Error checking and correction Error correction code Extensible Firmware Interface Electrostatic-sensitive components European standard Ground Chassis ground Hard Disk Drive Hard disk drive Height unit SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...
  • Page 96 US organization for tests and certifications accord- ing to own or binational standards (with CSA / Canada) standards. Universal Serial Bus Video Graphics Array Video adapter which meets industrial standard Watchdog Program monitoring with error detection and alarming. SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...

  • Page 97: Index

    Multi-touch device, 32 Mounting clip Installing multi-touch device, 32 EAC, 79 Mounting cutout Equipotential bonding, 36 Dimensions, 30 Ethernet, 69 Preparing, 30 EU Declaration of Conformity, 76 Mounting positions, 28 Multi-touch device Mounting, 32 SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...
  • Page 98 Protective conductor connection, 23 Quality control notification, 26 RJ45 Ethernet, 41 Safety instructions General, 16 Scope, 3 Securing the cables, 42 Setup, (BIOS Setup) SIMATIC IPC Image & Partition Creator, (Image & Partition Creator) SIMATIC IPC PX-32A Operating Instructions, 09/2023, A5E53092695-AA...
