X11SSL-CF/-nF User Manual
Onboard Power LED
The Onboard Power LED is located at LEDPWR on the motherboard. When this LED is on,
the system is on. Be sure to turn off the system and unplug the power cord before removing
or installing components. Refer to the table below for more information.
BMC Heartbeat LED
A BMC Heartbeat LED is located at LEDBMC on the motherboard. When LEDBMC is blinking,
the BMC is functioning normally. Refer to the table below for more information.
BMC
JSTBY1
Intel PCH
LSI 3008
MEGERAC
LICENSE
JNVME1
JSAS1
Onboard Power LED Indicator
LED Color
Off
Green
Onboard Power LED Indicator
LED Color
Green:
Blinking
VGA
LAN 2
LAN 1
2
LED BMC
JD1
JPL2
SP1 SP1
IPMI CODE
BT1
BAR CODE
X11SSL-CF_(-nF)
USB 8 (3.0)
REV:1.01
Designed in the USA
CPU
LED S1
1
USB 4/5
FANA FAN3
LED PWR
MAC CODE SAS CODE
Definition
System Off
(power cable not
connected)
System On
Definition
BMC: Normal
1. Onboard Power LED
USB 6/7 USB 0/1
(3.0) COM1
FAN4
2. BMC Heartbeat LED
IPMI_LAN
COM2
JTPM1
JPL1
JPG1 JPME2 JI2C2
JPB1 JI2C1
JBR1
JF1
