X11SSL-CF/-nF User Manual
LAN Ports
Two Gigabit Ethernet ports (LAN1 and LAN2) are located on the I/O back panel on the
motherboard. In addition, a dedicated IPMI LAN is located above USB 0/1 ports on the back
panel. All of these ports accept RJ45 cables. Please refer to the LED Indicator section for
LAN LED information.
LAN Ports 1/2
Pin Definition
Pin# Definition
1 TD0-
2 TD0+
3 TD1-
4 TD1+
5 TD2-
6 TD2+
7 TD3-
8 TD3+
9 COMMCT
10 GND
BMC
JSTBY1
Intel PCH
LSI 3008
MEGERAC
LICENSE
JSAS1 JNVME1
Pin# Definition
11 P3V3_Dual
12 Act LED (Yellow)
Link 1000 LED
13
(Amber)
Link 100 LED
14
(Green)
15 GND
16 GND
17 GND
18 GND
2
1
VGA
LAN 2
LAN 1
LED BMC
JD1
JPL2
SP1 SP1
IPMI CODE
BT1
BAR CODE
X11SSL-CF_(-nF)
USB 8 (3.0)
REV:1.01
Designed in the USA
CPU
LED S1
USB 4/5
FANA FAN3
LED PWR
MAC CODE SAS CODE
36
IPMI_LAN
Pin Definition
Pin# Definition
9
10 TD0+
11 TD0-
12 TD1+
13 TD1-
14 TD2+
15 TD2-
16 TD3+
17 TD3-
18 GND
3
USB 6/7 USB 0/1
COM1
(3.0)
FAN4
IPMI_LAN
COM2
JTPM1
JPL1
JPG1 JPME2 JI2C2
JBR1 JPB1 JI2C1
JF1
Pin# Definition
19 GND
Act LED
20
(Yellow)
Link 100 LED
21
(Green)
Link 1000 LED
22
(Amber)
23 SGND
24 SGND
25 SGND
26 SGND
1. LAN1
2. LAN2
3. IPMI LAN
