Specifications
Maximum altitude above sea level without derating
Maximum altitude above sea level with derating
Safety standards
EMC standards, Emission
EMC standards, Immunity

7.6 Cable Specifications

Cable lengths and cross sections
Max. motor cable length, screened/armoured
Max. cross section to motor, mains for MH1-MH3
Max. cross section DC terminals on enclosure type MH1-MH3
Maximum cross section to control terminals, rigid wire
Maximum cross section to control terminals, flexible cable
Minimum cross section to control terminals
Max. cross section to thermistor input (at motor connector)
7 7

7.7 Control Input/Output and Control Data

A)
Digital inputs
Programmable digital inputs
Terminal number
Logic
Voltage level
Voltage level, logic '0' PNP
Voltage level, logic '1' PNP
Voltage level, logic '0' NPN
Voltage level, logic '1' NPN
Maximum voltage on input
Input resistance, R
Digital input 29 as Pulse input
Analog inputs
Number of analog inputs
Terminal number
Terminal 53 mode
Terminal 54 mode
Voltage level
Input resistance, R
Max. voltage
Current level
Input resistance, R
Max. current
Analog output
Number of programmable analog outputs
Terminal number
Current range at analog output
Max. load to common at analog output
Max. voltage at analog output
Accuracy on analog output
Resolution on analog output
1) Terminal 42 and 45 can also be programmed as digital outputs.
40
i
A)
i
i
A)
Danfoss A/S © Rev. 06/2014 All rights reserved.
Operating Instructions
Max frequency 32 kHz Push-Pull-Driven & 5 kHz (O.C.)
EN/IEC 60204-1, EN/IEC 61800-5-1, UL 508C
EN61000-3-2, EN61000-3-12, EN55011, EN61000-6-4
EN61800-3, EN61000-6-1/2
Parameter 6-19: 1=voltage, 0=current
Parameter 6-29: 1=voltage, 0=current
0/4 to 20 mA (scalable)
Max. error: 0.4% of full scale
1000 m
3000 m
0.5 m
4 mm 2 /10 AWG
2
4 mm /10 AWG
2
2.5 mm /14 AWG
2
2.5 mm /14 AWG
0.05 mm 2 /30 AWG
2
4.0 mm
4
18, 19, 27, 29
PNP or NPN
0-24 V DC
<5 V DC
>10 V DC
>19 V DC
<14 V DC
28 V DC
Approx. 4 kΩ
2
53, 54
0-10 V
approx. 10 kΩ
20 V
<500 Ω
29 mA
2
1)
42, 45
0/4-20 mA
500 Ω
17 V
10 bit
