Specifications
7.1.2 FCP 106 Dimensions
7
7
Illustration 7.2 FCP 106 Dimensions
Enclosure type
MH1
MH2
MH3
Table 7.3 FCP 106 Dimensions
1) Power ratings relate to NO, see chapter 7.2 Electrical Data.
32
Operating Instructions
Y
X
1)
Length
Power
[mm]
[kW]
3x380-480 V
A
a
0.55-1.5
231.4
130
2.2-4.0
276.8
166
5.5-7.5
321.7
211
Danfoss A/S © Rev. 06/2014 All rights reserved.
Width
Height
Cable gland diameter
[mm]
[mm]
B
C
X
162.1
106.8
M20
187.1
113.2
M20
221.1
123.4
M20
Mounting
hole
Y
M20
M6
M20
M6
M25
M6
MG03L202
