Electrical Installation
4.3 EMC-Compliant Installation
1
7
L1
L2
L3
PE
1
PLC
2
Motor
3
Frequency converter
4
Min. 200 mm clearance between control cable, mains cable, and mains motor cable.
Illustration 4.2 EMC-compliant Electrical Installation, FCP 106
MG03L202
Operating Instructions
2
4
6
5
5
Control cables
6
Mains, 3-phase, and reinforced PE
7
Cable insulation (stripped)
Danfoss A/S © Rev. 06/2014 All rights reserved.
3
4
4
15
