5.4.2. Drinking water plant (dry)

5.4.2.1. Tightness check

The tightness check acc. to DIN EN 806-4 at drinking
water pipes is registered as a control pragram in the
ecom-DP3. Proceed as follows:
1. Scroll with the cursor keys <up/down> in the
menu "Drinking water / Drinking water plant dry"
to the menu point „Tightness check dry". Activate
the menu point with <Enter>.
2. Check if necessary the values of stabilisation time,
measurement time and test pressure with <F1>
(back with <ESC>).
3. Lock the gas pipe with a suitable adapter (test
stopple, high pressure stopple or one-pipe counter
cap).
4. Connect the components as described in
chapter 3.
5. Start the control program with <Enter> (the pump
of the instrument is building up the adjusted pres-
sure).
6. Wait for stabilisation time (if the pressure remains
in the range „test pressure +/- 10%" during stabilisa-
tion time, so the measurement time will start). If nec-
essary the stabilisation time can be terminated with
<F1>.
7. Once the measurement time is over, the result is
displayed and can be printed with <Print>.
8. If the menu „Tightness check dry" is selected
again, so the result can be called up with <F4> (as
long as the ecom-DP3 is on) or a new measurement
can be started with <F1>.
Page 24
