5.4.1.2. Pressure test

The pressure test acc. to DIN EN 806-4 at drinking
water pipes is registered as a control pragram in the
ecom-DP3. Proceed as follows:
1. Scroll with the cursor keys <up/down> in the
menu "Drinking water / Drinking water plant wet"
to the menu point „Pressure test wet". Activate the
menu point with <Enter>.
2. Check if necessary the values of stabilisation time,
measurement time and test pressure with <F1>
(back with <ESC>).
3. Connect the external pressure sensor to the
drinking water pipe.
4. Connect the external pressure sensor as de-
scribed in chapter 3.
5. Start the control program with <Enter> and and
built up the adjusted pressure.
6. Wait for stabilisation time (if the pressure remains
in the range „test pressure +/- 10%" during stabilisa-
tion time, so the measurement time will start). If nec-
essary the stabilisation time can be terminated with
<F1>.
7. Once the measurement time is over, the result is
displayed and can be printed with <Print>.
8. If the menu „Pressure test wet" is selected
again, so the result can be called up with <F4> (as
long as the ecom-DP3 is on) or a new measurement
can be started with <F1>.
Page 22
Drinking water plant
Pressure test wet
Set value 11.00bar
Built up pressure!
10min
10.23
30min
Drinking water plant
Pressure test wet
Stabilisation time
Res. time: 9:58min
11.05
Start Difference
Pressu 11.13bar -0.08bar
Temp. 22.6°C
Drinking water plant
Pressure test wet
Measur. in process
Res. time: 29:25min
11.05
Start Difference
Pressu 11.05bar
Temp. 22.6°C
Drinking water plant
Pressure test wet
Measurement 30:00min
Ini. Press 11.05bar
Fin. Press 11.05bar
Difference
Ini. temp.
End temp.
Difference
Forward w.:
Drinking water plant
Pressure test wet
Start new
measurement?
Select:
NO
YES
ecom-DP3
bar
bar
0.3°C
bar
0.00bar
0.0°C
0.0bar
22.6°C
22.6°C
0.0°C
