ZYBO™ FPGA Board Reference Manual
There are many aspects of the Zynq AP SoC architecture that are beyond the scope of this document. For a
complete and thorough description, refer to the Zynq Technical Reference Manual, available at www.xilinx.com.
Figure 3 depicts the external components connected to the MIO pins of the ZYBO. The Zynq Board Definition File
found on the Digilent ZYBO product page can be imported into EDK and Vivado Designs to properly configure the
PS to work with these peripherals.
Copyright Digilent, Inc. All rights reserved.
Other product and company names mentioned may be trademarks of their respective owners.
MIO 500 3.3 V Peripherals
Pin Pmod
0 JF7
1
2
3
4
5
6
7
8
9 JF8
10 JF2
11 JF3
12 JF4
13 JF1
14 JF9
15 JF10
Peripherals Peripherals
SPI Flash GPIO
CS
DQ0
DQ1
DQ2
DQ3
SCLK
LED4
SLCK FB
