Technical data, mains supply 3 x 525 - 690 V
According to international requirements
1. For type of fuse see section Fuses
2. American Wire Gauge.
3. Measured using 30 m screened motor cables at rated load and rated frequency.
4. Max. cable cross-section is the maximum possible cable cross-section allowed to be fitted on
the terminals. Min. cable cross-section is the minimum allowed cross-section. Always comply
with national and local regulations on min. cable cross-section.
5. Connection bolt 1 x M10 / 2 x M10 (mains and motor), connection bolt 1 x M8 / 2 x M8 (DC-bus).
MG.83.A2.02 - VLT is a registered Danfoss trademark
Output current
I
VLT, MAX
I
VLT, MAX
Output
Typical shaft output
Max. cable cross-section to
motor
Max. cable cross-section to
loadsharing and brake
Rated input current
Max. cable cross-section
power supply
Min. cable cross-section to
motor and power supply
Min. cable cross-section to
brake and loadsharing
Max. pre-fuses (mains) [-]/UL
3
Efficiency
Power loss
Weight
Weight
Weight
Enclosure
®
VLT
VLT type 8052 8062
I [A] (525-550 V) 56 76
VLT,N
(60 s) [A] (525-550 V) 62 84
I [A] (551-690 V) 54 73
VLT,N
(60 s) [A] (551-690 V) 59 80
S [kVA] (550 V) 53 72
VLT,N
S [kVA] (575 V) 54 73
VLT,N
S [kVA] (690 V) 65 87
VLT,N
[kW] (550 V) 37 45
[HP] (575 V) 50 60
[kW] (690 V) 45 55
2 4,5
[mm ]
2,4,5
[AWG]
2 4,5
[mm ]
2,4,5
[AWG]
I [A] (550 V) 60 77
L,N
I [A] (575 V) 58 74
L,N
I [A] (690 V) 58 77
L,N
2 4,5
[mm ]
2,4,5
[AWG]
2 4,5
[mm ]
2,4,5
[AWG]
2 4,5
[mm ]
2,4,5
[AWG]
1
[A] 125 160
0.97
[W] 1458 1717
IP 00 [kg]
IP 21/Nema1 [kg]
IP 54/Nema12 [kg]
IP 00, IP 21/Nema 1 and IP 54/Nema12
8000 AQUA
8072 8102 8122
90 113 137
99 124 151
86 108 131
95 119 144
86 108 131
86 108 130
103 129 157
55 75 90
75 100 125
75 90 110
2 x 70
2 x 2/0
2 x 70
2 x 2/0
89 110 130
85 106 124
87 109 128
2 x 70
2 x 2/0
35
2
10
8
200 200 250
0.97 0.98 0.98 0.98
1913 2262 2662
82
96
96
45
