323 Relay 1, output function
(RELAY1 FUNCTION)
Function:
This output activates a relay switch. Relay switch
01 can be used for indicating status and warnings.
The relay is activated when the conditions for the
relevant data values have been fulfilled.
Activation/deactivation can be programmed in
parameter 324 Relay 1, ON delay and parameter
325 Relay 1, OFF delay.
See General technical data.
Description of choice:
See data choice and connections in Relay outputs.
324 Relay 01, ON delay
(RELAY1 ON DELAY)
Value:
0 - 600 sec.
Function:
This parameter allows a delay of the cut-in time
of relay 1 (terminals 1-2).
Description of choice:
Enter the desired value.
325 Relay 01, OFF delay
(RELAY1 OFF DELAY)
Value:
0 - 600 sec.
Function:
This parameter makes it possible to delay the
cut-out time of relay 01 (terminals 1-2).
Description of choice:
Enter the desired value.
326 Relay 2, output function
(RELAY2 FUNCTION)
Value:
See functions of relay 2 on previous page.
Function:
This output activates a relay switch. Relay switch
2 can be used for indicating status and warnings.
The relay is activated when the conditions for the
relevant data values have been fulfilled.
See General technical data.
= factory setting. () = display text [] = value for use in communication via serial communication port
130
Description of choice:
See data choice and connections in Relay outputs.
327 Pulse reference, max. frequency
(PULSE REF. MAX)
Value:
100 - 65000 Hz at terminal 29
100 - 5000 Hz at terminal 17
Function:
This parameter is used to set the pulse value that must
correspond to the maximum reference, parameter
205 Maximum reference, Ref
The pulse reference signal can be connected
via terminal 17 or 29.
Description of choice:
Set the required maximum pulse reference.
0 sec.
328 Pulse feedback, max. frequency
(PULSE FDBK MAX.)
Value:
100 - 65000 Hz at terminal 33
Function:
This is where the pulse value that must correspond
to the maximum feedback value is set. The pulse
fedback signal is connected via terminal 33.
Description of choice:
Set the desired feedback value.
2 sec.
364 Terminal 42, bus control
(CONTROL OUTPUT 42)
365 Terminal 45, bus control
(CONTROL OUTPUT 45)
Value:
0.0 - 100 %
Function:
Through serial communication, a value between 0.1
and 100.0 is written to the parameter.
The parameter is hidden and cannot be
seen from the LCP.
MG.83.A2.02 - VLT is a registered Danfoss trademark
®
