Danfoss VLT 8000 AQUA series Operating Instructions Manual page 18

Ordering numbers, LC filter modules
Mains supply 3 x 200 - 240 V
LC filter LC filter
for VLT type enclosure
8006-8008 IP 00
8011 IP 00
8016 IP 00
8022 IP 00
8027 IP 00
8032 IP 00
8042 IP 00
8052 IP 00
8062 IP 00
Mains supply 3 x 380 - 480
LC filter LC filter
for VLT type enclosure
8006-8011 IP 20
8016 IP 00
8022 IP 00
8027 IP 00
8032 IP 00
8042 IP 00
8052 IP 00
8062 IP 00
8072 IP 20
8102 IP 20
8122 IP 20
8152 IP 20
8202 IP 20
8252 IP 20
8302 IP 20
8352 IP 20
8452 IP 20
8502 IP 20
8602 IP 20
Regarding LC filters for 525 - 600 V and VLT 8652,
380-480 V, please contact Danfoss.
NB!:
When using LC filters, the switching frequency
must be 4.5 kHz (see parameter 407).
For VLT 8452-8602 parameter 408 must be set to
LC filter fitted to obtain proper operation.
18
Rated current Max. output
at 200 V frequency
25.0 A 60 Hz
32 A 60 Hz
46 A 60 Hz
61 A 60 Hz
73 A 60 Hz
88 A 60 Hz
115 A 60 Hz
143 A 60 Hz
170 A 60 Hz
Rated current Max. output
at 400/480 V frequency
16 A / 16 A 120 Hz
24 A/ 21.7 A 60 Hz
32 A / 27.9 A 60 Hz
37.5 A / 32 A 60 Hz
44 A / 41.4 A 60 Hz
61 A / 54 A 60 Hz
73 A / 65 A 60 Hz
90 A / 78 A 60 Hz
106 A / 106 A 60 Hz
147 A / 130 A 60 Hz
177 A / 160 A 60 Hz
212 A / 190 A 60 Hz
260 A / 240 A 60 Hz
315 A / 302 A 60 Hz
395 A / 361 A 60 Hz
480 A / 443 A 60 Hz
600 A / 540 A 60 Hz
658 A / 590 A 60 Hz
745 A / 678 A 60 Hz
MG.83.A2.02 - VLT is a registered Danfoss trademark
®
VLT 8000 AQUA
Power
loss Order no.
110 W 175Z4600
120 W 175Z4601
150 W 175Z4602
210 W 175Z4603
290 W 175Z4604
320 W 175Z4605
600 W 175Z4702
600 W 175Z4702
700 W 175Z4703
Power
loss Order no.
175Z0832
170 W 175Z4606
180 W 175Z4607
190 W 175Z4608
210 W 175Z4609
290 W 175Z4610
410 W 175Z4611
480 W 175Z4612
500 W 175Z4701
600 W 175Z4702
750 W 175Z4703
750 W 175Z4704
900 W 175Z4705
1000 W 175Z4706
1100 W 175Z4707
1700 W 175Z3139
2100 W 175Z3140
2100 W 175Z3141
2500 W 175Z3142
