Torque. CT operation is achieved by maintaining a
constant U/f ratio over the operating range.
NB!:
It is important that the values set in parameters
102-106 Nameplate data correspond to the
nameplate data of the motor with respect to
either star coupling Y or delta coupling
102 Motor power, P
M,N
(MOTOR POWER)
Value:
0.25 HP (0.25 KW)
0.5 HP (0.37 KW)
0.75 HP (0.55 KW)
1 HP (0.75 KW)
1.5 HP (1.10 KW)
2 HP (1.50 KW)
3 HP (2.20 KW)
4 HP (3.00 KW)
5 HP (4.00 KW)
7.5 HP (5.50 KW)
10 HP (7.50 KW)
15 HP (11.00 KW)
20 HP (15.00 KW)
25 HP (18.50 KW)
30 HP (22.00 KW)
40 HP (30.00 KW)
50 HP (37.00 KW)
60 HP (45.00 KW)
75 HP (55.00 KW)
100 HP (75.00 KW)
125 HP (90.00 KW)
150 HP (110.00 KW)
200 HP (132.00 KW)
250 HP (160.00 KW)
300 HP (200.00 KW)
350 HP (250.00 KW)
400 HP (300.00 KW)
450 HP (315.00 KW)
500 HP (355.00 KW)
550 HP (400.00 KW)
600 HP (450.00 KW)
HP (500.00 KW)
700 HP (530.00 KW)
HP (560.00 KW)
HP (630.00 KW)
Depends on the unit
Function:
This is where to select the kW value P
corresponds to the rated power of the motor.
= factory setting. () = display text [] = value for use in communication via serial communication port
100
.
M,N
[25]
[37]
[55]
[75]
[110]
[150]
[220]
[300]
[400]
[550]
[750]
[1100]
[1500]
[1850]
[2200]
[3000]
[3700]
[4500]
[5500]
[7500]
[9000]
[11000]
[13200]
[16000]
[20000]
[25000]
[30000]
[31500]
[35500]
[40000]
[45000]
[50000]
[53000]
[56000]
[63000]
that
M,N
®
VLT 8000 AQUA
At the works, a rated kW value P
selected that depends on the type of unit.
Description of choice:
Select a value that equals the nameplate data on the
motor. There are 4 possible undersizes or 1 oversize
in comparison with the factory setting.
Also, alternatively it is possible to set the value of the
motor power infinitely variable value, see the procedure
for infinetely variable change of numeric data value .
103 Motor voltage, U
M,N
(MOTOR VOLTAGE)
Value:
200 V
208 V
220 V
230 V
240 V
380 V
400 V
415 V
440 V
460 V
480 V
500 V
550 V
575 V
660 V
690 V
Depends on the unit
Function:
This is where the rated motor voltage U
set for either star Y or delta
Description of choice:
Select a value that equals the nameplate data on
the motor, regardless of the mains voltage of the
frequency converter. Furthermore, alternatively it is
possible to set the value of the motor voltage infinitely
variably. Also refer to the procedure for infinitely
variable change of numeric data value.
104 Motor frequency, f
(MOTOR FREQUENCY)
Value:
50 Hz (50 HZ)
60 Hz (60 HZ)
MG.83.A2.02 - VLT is a registered Danfoss trademark
has been
M,N
[200]
[208]
[220]
[230]
[240]
[380]
[400]
[415]
[440]
[460]
[480]
[500]
[550]
[575]
[660]
[690]
is
M,N
.
M,N
[50]
[60]
