Tilt, Skew, and Pitch

Tilt, Skew, and Pitch
Be aware of the tolerance for the tilt, pitch, and skew of the symbol you are trying to scan.
3-8
EAN (13 digits) 37 mm
Symbol
0.33 mm (13
mil)
R > or = 25
R
mm
d 90 mm
0.9 (printed on photographic
PCS
paper)
MS-1 Scan Engine User Manual
0.39 mm
(15.6 mil)
R > or = 25
mm
120 mm
