Appendix D — Communications Protocol
Communications Protocol Command Table
Protocol Command
(Mnemonic displayed on menu)
RES
REQ
EOT
STX
ETX
ACK
NAK
XON
XOFF
A-10
Control Characters
(Entered in menu or
serial command)
^D
^E
^D
^B
^C
^F
^U
^Q
^S
Hex
Effect of Command
Value
04 Reset
05 Request
04 Reset
02 Start of Text
03 End of Text
06 Acknowledge
15 Negative Acknowledge
11 Begin Transmission
13 Stop Transmission
