Connect
Step 5 — Connect
Connection Wizard
To connect using the Connection Wizard:
• Click Connect on the menu toolbar, and then select Connection Wizard.
• Select RS-232 or USB to activate the appropriate display.
• Configure settings as required by the application, and click Connect.
Important: MS-1 demo kits are in USB Virtual COM mode by default, and ship with a
Virtual COM Cable. Select RS-232 in the dialog shown below to communicate with the
demo kit.
MS-1s that are sold in the standard 8-pack (FIS-0001-800XG) are in RS-232 by default.
Select RS-232 to communicate with the reader.
Important: If using the USB Virtual
COM cable, select RS-232.
RS-232 Connection Wizard
• When a connection is established, the green indicator in the status bar at the bottom
right of the screen will be visible:
Important: The MS-1 is in Continuous Read Mode by default. For best connection
results, be sure that no decodable symbols are within the reader's field of view while
attempting to connect.
1-6
USB Connection Wizard
