Terminal Window - Microscan MS-1 User Manual

Terminal Window

Terminal Window
Click this button to display the Terminal view.
The following view will appear:
Copy, paste, save
Clear screen
Macros listed
on this bar.
The Terminal allows you to send serial commands to the MS-1 by typing commands in the
Send text field or directly in the Terminal screen, by copying and pasting, or by using Macros.
The Terminal screen also displays symbol data or information from the MS-1.
You can right-click on the screen to bring up a menu of several options for managing
data in the Terminal view.
8-2
Type text here to
find matching text
in the Terminal
window.
Terminal
screen
Click on arrows to Add Macro,
Remove Macro, or Edit Macro.
Type serial commands
here, or directly in the
terminal screen.
Click on desired
Macro to run.
MS-1 Scan Engine User Manual
