Electrical Interface

Electrical Interface
Flex Cable Pinout (Host Side)
Pin
1
2
3
4
5
6
7
8
9
10
11
12
Flex Cable
Host end
(12 contacts)
2-2
Host RS-232 TTL
+5V Power (VCC)
TTL_RxD
Trigger Input
Power Enable
TTL_TxD
TTL_RTS
GND
USB_D+
LED (Engine Status)
TTL_CTS
Beeper (Decode Indicator)
USB_D–
MS-1 end
(12 contacts)
In/Out
MS-1 Scan Engine
MS-1 Scan Engine User Manual
In
In
In
In
Out
Out
In/Out
Out
In
Out
In/Out
