Microscan MS-1 User Manual page 17

Step 8 — Save Changes in ESP
To make changes to a configuration setting:
+
1. Left-click on the
to expand the
desired tree.
2. Double-click on the
desired parameter
and click once in the
selection box to view
options.
Saving Options
• Send, No Save. Changes will be lost when power is re-applied to the MS-1.
• Send and Save. This activates all changes in current memory and saves to the MS-1
for power-on.
• Send and Save, Including Factory. This activates all changes in current memory,
saves to the MS-1 for power-on, and saves the
MS-1 Scan Engine User Manual
4. Left-click again on the
open screen to complete
your selection.
3. Place your cursor in the
selection box, scroll down to
the setting you want to
change, and click once on
the setting.
5. Right-click on the open
screen and select Save to
Reader to implement the
command in the MS-1.
Communications Mode
Quick Start
setting.
1-9
