Serial Configuration Commands
Appendix C — Serial Configuration Commands
Note: For a list of utility commands such as read rate requests, device control options, and
reader status requests, see
Communications
Host Port Connections
Keyboard Mapping
Communications Mode
Host Port Protocol
Preamble
Postamble
Read Cycle
Trigger Mode
Serial Trigger Character
No Decode Timeout
Decodes Before Output
Number of Symbols
Start Trigger Character
Stop Trigger Character
Time Between Identical Decodes
Shutter Speed
No Read Message
Symbologies
Symbology Identifier
Code 39
Codabar
Interleaved 2 of 5
Code 128/EAN 128
Code 93
PDF417
DataBar-14 (RSS-14)
DataBar Limited (RSS Limited)
DataBar Expanded (RSS Expanded)
MSI Code
Plessey Code
Industrial 2 of 5
A-6
Serial Utility Commands.
<K100,baud rate,parity,stop bits,data bits>
<K116,keyboard layout,caps lock mode,number lock>
<K117,communications mode>
<K140,protocol>
<K141,status,preamble characters>
<K142,status,postamble characters>
<K200,trigger mode>
<K201,serial trigger character>
<K220,0,seconds>
<K221,decodes before output>
<K222,number of symbols>
<K229,start character>
<K230,stop character>
<K503,time between identical decodes>
<K544,shutter speed>
<K714,status,No Read message>
<K450,0,symbology identifier status>
<K470,status,check character status,check character output status,
0,0,minimum symbol length,full ASCII set>
<K471,status,0,start/stop match output status,0,symbol length status,
symbol length,check character status,check character output
status>
<K472,status,check character status,check character output status,
symbol length #1,symbol length #2>
<K474,status,0,minimum symbol length,1,1,0,application record
separator character>
<K475,status,0,minimum symbol length>
<K476,status>
<K482,status>
<K483,status>
<K484,status>
<K486,status,check character mode,check character output status,
0,minimum symbol length>
<K487,status,check character output status,0,minimum symbol
length>
<K488,status,check character status,check character output status,
format,symbol length #1,symbol length #2>
