COMBIVERT F6
INSTRUCTIONS FOR USE | INSTALLATION F6 HOUSING 4
Translation of the original manual
Document 20116235 EN 03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the COMBIVERT F6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for KEB COMBIVERT F6

Summary of Contents for KEB COMBIVERT F6

  • Page 1 COMBIVERT F6 INSTRUCTIONS FOR USE | INSTALLATION F6 HOUSING 4 Translation of the original manual Document 20116235 EN 03...

  • Page 3: Preface

    PreFAce Preface The described hard- and software are developments of the KEB Automation KG. The enclosed documents correspond to conditions valid at printing. Misprint, mistakes and technical changes reserved. Signal words and symbols Certain operations can cause hazards during the installation, operation or thereafter.

  • Page 4: Laws And Guidelines

    The customer may use the instruction manual as well as further documents or parts from it for internal purposes. Copyrights are with KEB Automation KG and remain valid in its entirety. Other wordmarks or/and logos are trademarks (™) or registered trademarks (®) of their...

  • Page 5: Table Of Contents

    TAbLe OF cONTeNTS Table of contents Preface ..............................3 Signal words and symbols ......................3 More symbols ..........................3 Laws and guidelines ........................4 Warranty ............................4 Support ............................4 Copyright ............................4 Table of contents ........................... 5 List of Figures ............................8 List of Tables ............................9 Glossary ..............................
  • Page 6 3.3.4 Through-mount version water-cooler IP20, IP54 ..............43 3.3.5 Control cabinet installation ....................44 4 Installation and connection ........45 4.1 Overview of the cOMbIVerT F6 ....................45 4.2 connection of the power unit ....................... 48 4.2.1 Connection of the voltage supply ..................48 4.2.1.1 Terminal block X1A for 400 V units ..................
  • Page 7 TAbLe OF cONTeNTS 4.2.5.4 Motor cable length and conducted interferences at AC supply ........55 4.2.5.5 Motor cable length for parallel operation of motors ............56 4.2.5.6 Motor cable cross-section ....................56 4.2.5.7 Interconnection of the motor .................... 56 4.2.5.8 Connection of the temperature monitoring and brake control (X1C) ....... 57 4.2.6 Connection and use of a braking resistor ................

  • Page 8: List Of Figures

    LIST OF FIGUreS List of Figures Figure 1: Switch-off time t depending on the overload I/IN (OL) ............. 30 Figure 2: Typical overload characteristics in the lower output frequencies (OL2) Example. Unit size 19 ........................32 Figure 3: Block diagram of the energy flow ..................37 Figure 4: Switching behaviour of the fans example heat sink fan ...........

  • Page 9: List Of Tables

    LIST OF TAbLeS List of Tables Table 1: Type code ........................23 Table 2: Climatic environmental conditions ................... 24 Table 3: Mechanical ambient conditions ..................25 Table 4: Chemical / mechanical active substances ............... 25 Table 5: Device classification......................26 Table 6: Electromagnetic compatibility ..................26 Table 7: Overview of the 400V unit data ..................

  • Page 10: Glossary

    Overload COMBIVERT KEB drive converters OSSD Output signal swithching device; - an COMBIVIS KEB start-up and parameterizing output signal that is checked in regu- software lar intervals on its shutdown. (safety DC current or voltage technology) Demineralized water, also referred to...
  • Page 11 GLOSSAry Synchronous serial interface for encoder Safety function „Safe Torque Off“ in accordance with IEC 61800-5-2 Incremental signal with an output voltage up to 5 V Universal serial bus VARAN Real-time Ethernet bus system...

  • Page 12: Standards For Drive Converters / Control Cabinets

    STANDArDS FOr DrIVe cONVerTerS / cONTrOL cAbINeTS Standards for drive converters / control cabinets Product standards that apply directly to the drive converter EN 61800-2 Adjustable speed electrical power drive systems - Part 2: General requirements - Rating specifications for low voltage adjustable frequency a.c. power drive systems (VDE 0160-102, IEC 61800-2) EN 61800-3 Speed-adjustable electrical drives. Part 3: EMC requirements and specific test methods (VDE 0160-103, IEC 61800-3)

  • Page 13: Standards That Are Used In The Environment Of The Drive Converter

    STANDArDS FOr DrIVe cONVerTerS / cONTrOL cAbINeTS EN 61000-4-4 Electromagnetic compatibility (EMC) - Part 4-4: Testing and measurement techniques - Electrical fast transient/burst immunity test (IEC 61000-4-4); German version EN 61000-4-4 EN 61000-4-5 Electromagnetic compatibility (EMC) - Part 4-5: Testing and measurement techniques - Surge immunity test (IEC 61000-4-5);...

  • Page 14: Basic Safety Instructions

    Hazards and risks through ignorance. ► Read the instruction manual ! ► Observe the safety and warning instructions ! ► If anything is unclear, please contact KEB Automation KG ! 1.1 Target group This instruction manual is determined exclusively for electrical personnel. Electrical per- sonnel for the purpose of this instruction manual must have the following qualifications: •...

  • Page 15: Installation

    bASIc SAFeTy INSTrUcTIONS Drive converters contain electrostatic sensitive components. ► Avoid contact. ► Wear ESD-protective clothing. Do not store drive converters • in the environment of aggressive and/or conductive liquids or gases. • with direct sunlight. • outside the specified environmental conditions. 1.3 Installation DANGer Do not operate in an explosive environment! ►...

  • Page 16: Electrical Connection

    bASIc SAFeTy INSTrUcTIONS 1.4 electrical connection DANGer Voltage at the terminals and in the device ! Danger to life due to electric shock ! ► Never work on the open device or touch exposed parts. ► For any work on the unit switch off the supply voltage and secure it against switching on.

  • Page 17: Emc-Compatible Installation

    Accordng to EN 60204-1 it is permissible to disconnect already tested com- ponents. Drive converters of the KEB Automation KG are delivered ex works voltage tested to 100% according to product standard. 1.4.3 Insulation measurement An insulation measurement (in accordance with EN 60204-1 chapter 18.3) with DC...

  • Page 18: Start-Up And Operation

    • Never touch terminals, busbars or cable ends. Observe the following instructions if the drive converter for more than one year was not in operation before start-up. www.keb.de/fileadmin/media/Manuals/knowledge/04_techinfo/00_gene- ral/ti_format_capacitors_0400_0001_gbr.pdf NOTICE continuous duty (S1) with average duty > 60% ! Premature aging of electrolytic capacitors ! ►...

  • Page 19: Maintenance

    For applications that require cyclic switching on and off of the drive converter, maintain an off-time of at least 5 min after the last switch on. If you require shorter cycle times please contact KEB Automation KG. Short-circuit proof The drive converters are conditional short-circuit proof. After resetting the internal pro- tection devices, the function as directed is guaranteed.

  • Page 20: Repair

    Drive converters with safety function are limited to a service life of 20 years. Thereafter the devices must be replaced. Drive converters of the KEB Automation KG are professional, electronic devices exclu- sively for further industrial processing (so-called B2B devices). Thus the marking does not occur with the symbol of the crossed-out wheeled bin, but by the word mark and the date of manufacture.

  • Page 21: Product Description

    The used semiconductors and components of the KEB Automation KG are developed and dimensioned for the use in industrial products. Restriction If the KEB COMBIVERT F5 is used in machines, which work under exceptional condi- tions or if essential functions, life-supporting measures or an extraordinary safety step must be fulfilled, the necessary reliability and security must be ensured by the machine builder.

  • Page 22: Product Features

    COMBIVERT F6 Power range: 30...55 kW / 400 V Housing: The COMBIVERT F6 is characterized by the following features: • Operation of three-phase asynchronous motors and three-phase synchronous motors, in operating modes open-loop or closed-loop with and without speed feedback •...

  • Page 23: Part Code

    Control type COMPACT Multi-encoder interface, CAN and STO on ® 2) Board, EtherCAT or VARAN on Board ® 1) Series COMBIVERT F6 Inverter size 12…32 Table 1: Type code The type code is not used as order code, but only for identification! EtherCAT is a registered trademark and patented technology licensed ®...

  • Page 24: Technical Data

    3 Technical Data Unless otherwise indicated, all electrical data in the following chapter refer to a 3-phase AC mains. 3.1 Operating conditions 3.1.1 climatic environmental conditions Storage Standard class Descriptions Surrounding temperature EN 60721-3-1 -25…55 °C Relative humidity EN 60721-3-1 5…95 % (without condensation) Storage height –...

  • Page 25: Mechanical Ambient Conditions

    3.1.2 Mechanical ambient conditions Storage Standard class Descriptions Vibration amplitude 0.3 mm (2…9 Hz) Vibration limits EN 60721-3-1 Acceleration amplitude 1 m/s² (9…200 Hz) Shock limit values EN 60721-3-1 40 m/s²; 22 ms Transport Standard class Descriptions Vibration amplitude 3.5 mm (2…9 Hz) Vibration limits EN 60721-3-2 Acceleration amplitude 10 m/s²...

  • Page 26: Electrical Operating Conditions

    3.1.4 electrical operating conditions 3.1.4.1 Device classification requirement Standard class Descriptions – EN 61800-5-1 Overvoltage category EN 60664-1 – Non-conductive pollution, occasional conden- Pollution degree EN 60664-1 sation when PDS is out of service. Table 5: Device classification 3.1.4.2 Electromagnetic compatibility For devices without an internal filter, an external filter is required to comply with the following limits.

  • Page 27: Unit Data Of The 400V Units

    3.2 Unit data of the 400V units 3.2.1 Overview The technical data are for 2/4-pole standard motors. With other pole numbers the drive converter must be dimensioned onto the rated motor current. Contact KEB for special or medium frequency motors. Inverter size...

  • Page 28: Voltage And Frequencies

    UNIT DATA OF THe 400V UNITS 3.2.2 Voltage and frequencies Rated input voltage Rated mains voltage (USA) N_UL Input voltage range 280...550 Input phases Mains frequency / Hz 50 / 60 Mains frequency tolerance ± f / Hz Table 8: Input voltages and frequencies of the 400V units DC link rated voltage @ U = 400V...

  • Page 29: Input And Output Currents/ Overload

    UNIT DATA OF THe 400V UNITS 3.2.3 Input and output currents/ overload Inverter size Rated input current @ U = 400V Rated input current @ U = 480V IN_UL Rated input current @ U = 565V N_dc IN_dc Rated input current @ U = 680V N_dc IN_dc_UL...

  • Page 30: Overload Characteristic (Ol)

    UNIT DATA OF THe 400V UNITS 3.2.3.1 Overload characteristic (OL) All drive converters can be operated at rated switching frequency with an utilization of 150 % for 60 s. Restrictions: • The thermal design of the heat sink is based on the rated current and the maximum surrounding temperature.

  • Page 31: Frequency-Dependent Maximum Current (Ol2)

    UNIT DATA OF THe 400V UNITS Operation in the range of the thermal overload limit Due to the high steepness of the overload characteristic, the duration of a permissible overload in this range cannot be determined exactly. Therefore, the design of the drive converter should be assumed to have a maximum overload time of 300 s.

  • Page 32: Figure 2: Typical Overload Characteristics In The Lower Output Frequencies (Ol2) Example

    UNIT DATA OF THe 400V UNITS The following characteristics indicate the permissible maximum current for the output frequency values 0 Hz, 3 Hz, 6 Hz, 10 Hz 25 Hz and 50 Hz. If the switching frequencies are different, there is an interpolation between the characteristics. Unit size 19 is repre- sented exemplary.

  • Page 33: Table 13: Frequency-Dependent Maximum Current For Unit Size 19

    UNIT DATA OF THe 400V UNITS The values for the respective unit size are listed in the following tables. Frequency-dependent maximum current Inverter size 19 (4 kHz) Output frequency / Hz 2 kHz 4 kHz Frequency-dependent maximum current @ f 8 kHz 12 kHz 16 kHz...

  • Page 34: Switching Frequency And Temperature

    UNIT DATA OF THe 400V UNITS 3.2.4 Switching frequency and temperature Inverter size Rated switching frequency / kHz Max. switching frequency / kHz S_max Min. switching frequency / kHz S_min Max. heat sink temperature / °C Temperature for derating the switching frequency / °C Temperature for uprating the switching frequency / °C...

  • Page 35: Power Dissipation At Nominal Operating

    UNIT DATA OF THe 400V UNITS 3.2.5 Power dissipation at nominal operating Inverter size Power dissipation at nominal operating 1082 Power dissipation at DC supply D_dc Table 18: Power dissipation of the 400V units Rated operation corresponds to U = 400 V; f = 50 Hz (typically value) 3.2.6 Protection of the drive converter Fuse / A...

  • Page 36: Dc Link / Braking Transistor Function Gtr7

    UNIT DATA OF THe 400V UNITS 3.2.7 Dc link / braking transistor function GTr7 Activation of the braking transistor function In order to use the braking transistor (GTR7), the function must be activated with parameter "is30 braking transistor function". For more information => F6 Programming manual.

  • Page 37: Figure 3: Block Diagram Of The Energy Flow

    UNIT DATA OF THe 400V UNITS Inverter Rectifier DC link Motor GTR7 out_dc in_dc Braking DC Out DC in resistor Figure 3: Block diagram of the energy flow ATTENTION Destruction of the drive converter! ► If the error "ERROR GTR7 always ON" occurs, the drive converter must be disconnected from the mains within 5 minutes!

  • Page 38: Fan

    UNIT DATA OF THe 400V UNITS 3.2.8 Fan Inverter size Number Interior fan Speed-variable Number Heat sink fan Speed-variable Table 21: The fans are speed adjustable! Depending on the setting of the software they are automatically controlled to high or low speed. ATTENTION Destruction of the fan! ►...

  • Page 39: Switching Behaviour Of The Fans

    UNIT DATA OF THe 400V UNITS 3.2.8.1 Switching behaviour of the fans The fans have different switch-on and switch-off points. The switching point for the switch-on temperature ① and the maximum speed level ③ of the fans are adjustable. The switching point for the switch-off temperature ② cannot be changed. ③...

  • Page 40: Dimensions And Weights

    DIMeNSIONS AND WeIGHTS 3.3 Dimensions and weights 3.3.1 built-in version air cooler *104,5 Housing Weight 13.8 kg Dimensions All dimensions in mm Optional shield plate Figure 5: Dimensions mounted version air cooler...

  • Page 41: Built-In Version Water Cooler

    DIMeNSIONS AND WeIGHTS 3.3.2 built-in version water cooler 86,5 Housing Weight 12.2 kg Dimensions All dimensions in mm Figure 6: Dimensions built-in version water cooler...

  • Page 42: Through-Mount Version Air-Cooler Ip20, Ip54

    DIMeNSIONS AND WeIGHTS 3.3.3 Through-mount version air-cooler IP20, IP54 187,5 (43,5) 41,5 Housing Weight 13.6 kg Dimensions All dimensions in mm Figure 7: Dimensions through-mount version air-cooler IP20, IP54 IP54 zone: heat sink underneath the mounting plate. For proper installation, the enclosed seal (40F6T45-0002) must be installed between heat sink and housing (e.g.

  • Page 43: Through-Mount Version Water-Cooler Ip20, Ip54

    DIMeNSIONS AND WeIGHTS 3.3.4 Through-mount version water-cooler IP20, IP54 74,5 (43,5) 187,5 41,5 Housing Weight 12 kg Dimensions All dimensions in mm Figure 8: Dimensions push-through version water-cooler IP20, IP54 IP54 zone: heat sink underneath the mounting plate. For proper installation, the enclosed seal (40F6T45-0002) must be installed between heat sink and housing (e.g.

  • Page 44: Control Cabinet Installation

    DIMeNSIONS AND WeIGHTS 3.3.5 control cabinet installation Power dissipation for the control cabinet dimension => „Power dissipation at nominal oper- ating“. A lower value can be used here depending on the operating mode/load. Dimen- Mounting distances Distance in mm Distance in inch sion Distance to preceding elements in the control cab- inet door.

  • Page 45: Installation And Connection

    OVerVIeW OF THe cOMbIVerT F6 4 Installation and connection 4.1 Overview of the cOMbIVerT F6 Housing 4 Name Description Shield clambs for shielded control ― lines. Attachment points for optional shield plate. The shielding e.g. from the motor cable is laid on ―...

  • Page 46: Figure 12: F6 Housing 4 Front View

    OVerVIeW OF THe cOMbIVerT F6 Housing 4 Name Description Shield clambs for shielded control ― lines. Protective earth; at connection to protective earth each terminal may be assigned only once. Power circuit terminals for: • Mains input • Braking resistor •...

  • Page 47: Figure 13: F6 Housing 4 Rear View With Control Board Compact

    Figure 13: F6 housing 4 rear view with control board COMPACT Further views can be found in the respective control board manual. Instructions for use COMBIVERT F6 control board COMPACT https://www.keb.de/fileadmin/media/Manuals/dr/ma_dr_f6-cu-k- inst-20144795_en.pdf Instructions for use COMBIVERT F6 control board APPLICATION https://www.keb.de/fileadmin/media/Manuals/dr/ma_dr_f6-cu-a-...

  • Page 48: Connection Of The Power Unit

    ► Never exchange mains input and motor output ! 4.2.1 connection of the voltage supply The COMBIVERT F6 housing 4 can be supplied by mains via terminals L1, L2 and L3. The use of DC terminals for feed-in is permitted only permitted with external precharging.

  • Page 49: Terminal Block X1A For 400 V Units

    cONNecTION OF THe POWer UNIT 4.2.1.1 Terminal block X1A for 400 V units cross-section for Tightening Name Function terminal connection torque Mains connection 3-phase Connection for Flexible line with braking resistor wire-end ferrule (between +R and R) 1.5...35 mm² DC connection, (without wire-end connection for ferrule up to max.

  • Page 50: Protective Earth And Function Earth

    The use of the functional earth (FE) is not required if the frequency inverter is EMC-technically wired as described in the manual => Before starting. The functional earth may not be wired green / yellow! Notes on EMC-compatible installation can be found here. www.keb.de/fileadmin/media/Manuals/emv/0000neb0000.pdf...

  • Page 51: Ac Connection

    Required for compliance with the limit values in accordance with EN 61800-3. HF filter for IT systems ⑥ KEB COMBIVERT Figure 17: Connection of the mains supply 400 V / 3-phase 4.2.3.2 Supply line The conductor cross-section of the supply line is determined by the following factors: •...

  • Page 52: Note On Hard Power Systems

    cONNecTION OF THe POWer UNIT 4.2.3.3 Note on hard power systems The service life of drive converters with voltage DC link depends on the DC voltage, surrounding temperature and the current load of the electrolytic capacitors in the DC link. The use of mains chokes can increase the service life of the condensators to a con- siderable extent, especially when connecting to „hard“...

  • Page 53: Dc Connection

    Type aR Fuses Pay attention to the permissible voltage range ! max. occurring DC voltage of 840 V KEB COMBIVERT Figure 18: Connection at DC voltage supply The use of DC terminals for feed-in is permitted only permitted with external precharging.

  • Page 54: Connection Of The Motor

    OF THe POWer UNIT 4.2.5 connection of the motor 4.2.5.1 Wiring of the motor Legend KEB COMBIVERT Apply motor cable, shielding on both sides over a large surface on the bare metallic frame or mount- TA1 TA2 ing plate (remove paint if necessary)

  • Page 55: Selection Of The Motor Line

    The maximum motor cable length is depending on the capacity of the motor cable as well as on the EMC emitted interference. External measures must be taken here (e.g. the use of a line filter). The following information is valid for the operation under rated conditions and the use of KEB listed filters under chapter => „Filters and chokes“! Max. motor cable length shielded max. leakage...

  • Page 56: Motor Cable Length For Parallel Operation Of Motors

    cONNecTION OF THe POWer UNIT 4.2.5.5 Motor cable length for parallel operation of motors The resulting motor cable length for parallel operation of motors, or parallel installation with multiple cables arises from the following formula: resulting motor cable length = ∑single cable length x √Number of motor cables 4.2.5.6 Motor cable cross-section The motor cable cross-section is dependent •...

  • Page 57: Connection Of The Temperature Monitoring And Brake Control (X1C)

    OF THe POWer UNIT 4.2.5.8 Connection of the temperature monitoring and brake control (X1C) A switchable KTY84/PTC evaluation is implemented in the COMBIVERT F6. The de- sired operating mode can be adjusted via the software.If the evaluation is not required, it must be deactivated via software (=>...

  • Page 58: Figure 25: Connection Of A Kty Sensor

    cONNecTION OF THe POWer UNIT KTY sensors are polarized semiconductors and must be operated in forward direction! To this connect the anode to TA1 and the cathode to TA2! Non-observance leads to incorrect measurements in the upper temperature range. A protection of the motor winding is then no longer guaranteed.

  • Page 59: Connection And Use Of A Braking Resistor

    ► Cover hot surfaces safe-to-touch. ► Before touching, check the surface. ► If necessary, attach warning signs on the system. 4.2.6.1 Installation instructions for side-mounted braking resistors Instructions for the installation of intrinsically safe brak- ing resistors https://www.keb.de/fileadmin/media/Manuals/dr/ma_dr_ Chapter „Installation in- safe-braking-resistors-20106652_en.pdf structions“.

  • Page 60: Terminal Block X1A Connection Braking Resistor

    Intrinsically safe braking resisitors behave in error case such as a safety fuse. They interrupt themselves without fire risk. More information about intrinsically safe braking resistors http://www.keb.de/fileadmin/media/Manuals/dr/ma_dr_safe-braking-re- sistors-20106652_en.pdf 4.2.6.4 Using a non-intrinsically safe braking resistor Using a non-intrinsically safe braking resistor with extend- ed temperature monitoring.

  • Page 61: Accessories

    Material number Shield plate mounting kit 00F6V80-4001 Table 25: Shield plate mounting kit 4.3.3 Side-mounted braking resistors Technical data and design about intrinsically safe braking resistors => https://www.keb.de/fileadmin/media/Manuals/dr/ma_dr_ safe-braking-resistors-20106652_en.pdf Technical data and design about non-intrinsically safe braking resistors => https://www.keb.de/fileadmin/media/Manuals/ dr/ma_dr_braking-resistors-20116737_en.pdf...

  • Page 62: Installation And Operation Of Water-Cooled Devices

    HeAT SINk AND OPerATING PreSSUre 5 Installation and Operation of Water-cooled Devices The use of water-cooled KEB COMBIVERT drive converters is offered, because there are process-caused coolants available with some applications. However, the following instructions must be observed. 5.1 Heat sink and operating pressure Max.

  • Page 63: Requirements On The Coolant

    reqUIreMeNTS ON THe cOOLANT 5.3 requirements on the coolant The requirements on the coolant are depending on the ambient conditions, as well as from the used cooling system. General requirements on the coolant: requirement Description Standards Corrosion protection according to 12502-1...5, water treatment and use of ma- terials in cooling systems according to VGB R 455 P...

  • Page 64: Connection Of The Cooling System

    Pipe diameter inside: 7...8 mm Figure 28: Open pipe ends for the connection of the cooling system Straight screw-in connections, cutting rings and union nuts (e.g. from Parker Ermeto) can be used for the connection of the cooling system. KEB recommends the use of a flow switch in order to monitor the flow in the cooling system.

  • Page 65: Coolant Temperature And Moisture Condensation

    cOOLANT TeMPerATUre AND MOISTUre cONDeNSATION 5.5 coolant temperature and moisture condensation The inlet temperature may not exceed 40°C. The maximum heat sink tem- perature is 90°C or 95°C depending on the power unit and overload capacity => „Switching frequency and temperature“.
  • Page 66 cOOLANT TeMPerATUre AND MOISTUre cONDeNSATION Temperature control The cooling can be switched on by means of a pneumatic valve or a solenoid valve, which is connected uptream by a relay. The valves for temperature control must be used in the flow line of the cooling circuit in order to avoid pressure surges. All conventional valves can be used. Make sure that the valves are working properly and do not clamp. ATTENTION Destruction of the heat sink at storage of water-cooled devices! Observe the following points when storing water-cooled devices:...

  • Page 67: Coolant Heating

    cOOLANT HeATING 5.6 coolant heating The following graphic shows examples of measurements with different flow rates. ΔT / K 5 l/min 10 l/min 20 l/min 30 l/min 40 l/min 50 l/min 100 l/min Pv / kW Figure 29: Coolant heating depending on power loss and flow rate with water 5.7 Typical pressure drop of the heat sink →...

  • Page 68: Certification

    cerTIFIcATION 6 Certification 6.1 ce-Marking CE marked drive converters were developed and manufactured to comply with the reg- ulations of the Low-Voltage Directive and EMC directive. The harmonized standards of the series EN 61800-5-1 EN 61800-3 were used. For further information regarding the CE declarations of conformity. =>...

  • Page 69: Ul Certifications

    6.2 UL certifications Acceptance according to UL is marked at KEB drive converters with the adjacent logo on the nameplate. To be conform according to UL for use on the North American and Canadian Market the following additionally instructions must be observed (original text of the UL-File): •...

  • Page 70: Further Informations And Documentation

    6.3 Further informations and documentation You find supplementary manuals and instructions for the download under https://www.keb.de/de/service/downloads General instructions • EMC and safety instructions • Manuals for control boards, safety modules, fieldbus modules, etc. Instruction and information for construction and development • Input fuses in accordance with UL • Programming manual for control and power unit •...

  • Page 71: Revision History

    reVISION HISTOry 7 revision History Version Date Description 2016-04 Prototype 2016-09 Pre-series 2017-02 Pre-series, unit size 22 added, new CI 2017-07 Series, UL certification included, water cooling Technical data corrections. 2018-09 Figures of the overload characteristics adapted.
  • Page 72 NOTES...
  • Page 73 Room 1709, 415 Missy 2000 725 Su Seo Dong E-Mail: vb.belgien@keb.de Internet: www.keb.de Gangnam Gu 135- 757 Seoul Republic of Korea Tel: +82 2 6253 6771 Fax: +82 2 6253 6770 E-Mail: vb.korea@keb.de KEB South America - Regional Manager brazil Rua Dr.
  • Page 74 Automation with Drive www.keb.de KEB Automation KG Suedstrasse 38 32683 Barntrup Tel. +49 5263 401-0 E-Mail: info@keb.de...
