7) Fit the joiner wire into the elevators.
Check to make sure the elevators are in
alignment with each other by placing the
assembly on a flat surface. It may be nec-
essary to bend the joiner wire slightly to
align both elevator halves.
8) Place the joiner wire in the slot for the
stabilizer. Once the joiner is in position,
slide the stabilizer into the slot in the fu-
selage.
9) When you are sure that everything is
aligned correctly, mix up a generous
amount of 30 Minute Epoxy. Apply a thin
layer to the top and bottom of the stabi-
lizer mounting area and to the stabilizer
mounting platform sides in the fuselage.
Slide the stabilizer in place and realign.
Double check all of your measurements
once more before the epoxy cures. Hold
the stabilizer in place with T-pins or mask-
ing tape and remove any excess epoxy us-
ing a paper towel and rubbing alcohol.
WWW.SEAGULLMODELS.COM
Epoxy.

VERTICAL FIN INSTALLATION.

1) Place the fin in the slot on the top of the
fuselage. While holding the vertical stabiliz-
er firmly in place, use a pen and draw a line
on each side of the vertical stabilizer where it
meets the top of the fuselage.
4) Remove the fin from the fuselage. Using
a modeling knife, remove the covering from
below the lines you drew.
Pen.
Knife.
