Seagull Models Magic Star 3D EP Assembly Manual page 9

3) Attach the motor to the front of the
electric motor box using four 4mm blind
nut, four M3x10mm hex head bolts to se-
cure the motor. Please see picture shown.
WWW.SEAGULLMODELS.COM
4 mm
4 mm
Blind nut.
.
4) Attach the motor to the front of the
electric motor box using four 4mm blind
nut, four M3x10mm hex head bolts to se-
cure the motor. Please see picture shown.
Epoxy
76 mm
Balsa stick.
Epoxy
M3x10mm
9
