Firmware
Downloading Application Code to the MS-1 without a Demo Board
Pin
Pin 8
Pin 11
Pin 12
1. Connect to the MS-1 via ESP.
2. Verify your current firmware using
3. Set Pin 8, Pin 11, and Pin 12 of the MS-1 to Firmware Update status (see Hardware
Signal Settings table above).
4. Select MS-1 from the Target Device dropdown menu.
5. Select 8MHz from the Crystal Frequency dropdown menu.
6. Select the new firmware file from the Hex File dropdown menu.
(Continued on next page)
9-6
Hardware Signal Settings
Decoded Operation
High
High
High
Firmware Verification
Click the Start button in
ESP Utilities to open the
firmware update utility.
Firmware Update
Low
Low
High
in ESP Utilities.
