Industrial Electronic Devices
CHARACTERISTICS:
The configurable "PROFIBUS Master / Modbus TCP Slave - Converter" allows the following characteristics:
Triple isolation between Modbus/PROFIBUS, Modbus/Power Supply, PROFIBUS/Power Supply.
Mountable on 35mm Rail DIN;
Power Supply 8...24V AC or 12...35V DC;
Temperature range -40°C to 85°C.
CONFIGURATION:
You need Compositor SW67579 software on your PC in order to perform the following:
Define the parameter of the PROFIBUS;
Define the parameter of the Modbus line;
Define the PROFIBUS network.
ADFweb.com Srl – IT31010 – Mareno – Treviso
User Manual PROFIBUS Master / Modbus TCP Slave - Converter
Document code: MN67579_ENG
INFO:
www.adfweb.com
Revision 2.002
Page 6 of 32
