ADF Web PROFIBUS Master User Manual page 28

Industrial Electronic Devices
Read with Input Register / Status Function enabled
Data in reading:
Input Register
Input Register
Input Register
Input Register
Data in writing:
Holding Register
Holding Register
Holding Register
Holding Register
Note:
The data can be read/written as single bits too using Input/Coil Status (Function 02 and Functions 01/05/15).
ADFweb.com Srl – IT31010 – Mareno – Treviso
Type Address
0
1
2
.
121
Type Address
0
1
2
.
121
User Manual PROFIBUS Master / Modbus TCP Slave - Converter
Document code: MN67579_ENG
Function Description
Input Bytes 0-1 of PROFIBUS side
04
Input Bytes 2-3 of PROFIBUS side
04
Input Bytes 4-5 of PROFIBUS side
04
Input Bytes 242-243 of PROFIBUS side
04
Function Description
R: 03
Output Bytes 0-1 of PROFIBUS side
W: 06/16
R: 03
Output Bytes 2-3 of PROFIBUS side
W: 06/16
R: 03
Output Bytes 4-5 of PROFIBUS side
W: 06/16
R: 03
Output Bytes 242-243 of PROFIBUS side
W: 06/16
INFO:
Revision 2.002 Page 28 of 32
