PROFIBUS DEVICE:

By pressing the "Add Slave PROFIBUS" and
the "PROFIBUS Network" window (Fig. 4) the "PROFIBUS Device" window appears (Fig. 6).
In this window is possible to:
Set the PROFIBUS Slave ID
PROFIBUS");
Select the Modules present in the
PROFIBUS Slave from the Available
Modules in GSD file ("Module
Selection");
Modify the User Parameters (if present)
of the PROFIBUS device
Parameters");
Modify the Parameters (if present) of the
Module Selected ("Module
Parameters");
Watch Features and Baudrate supported
from the PROFIBUS device
("Capabilities");
Select the Sync, Freeze and Reset of
Data Options ("Options").
ADFweb.com Srl – IT31010 – Mareno – Treviso
"Modify Slave
("ID Slave
("User
Figure 6: "PROFIBUS Device" window
