MODBUS MAP:

On Modbus side, the map is created automatically. In relation to the configuration defined, it is possible to have two different maps. Each
PROFIBUS Slave will be mapped into a different virtual Modbus ID (in relation to the field "ID Slave Modbus" of "PROFIBUS Network ->
PROFIBUS Device" section)
Read with Input Register / Status Function not enabled
Data in reading:
Holding Register
Holding Register
Holding Register
Holding Register
Data in writing:
Holding Register
Holding Register
Holding Register
Holding Register
Note:
The data can be read/written as single bits too using Coil Status (Function 01 and Functions 05/15).
ADFweb.com Srl – IT31010 – Mareno – Treviso
Type Address
0
1
2
.
121
Type Address
0
1
2
.
121
User Manual PROFIBUS Master / Modbus TCP Slave - Converter
Document code: MN67579_ENG
Function Description
Input Bytes 0-1 of PROFIBUS side
03
Input Bytes 2-3 of PROFIBUS side
03
Input Bytes 4-5 of PROFIBUS side
03
Input Bytes 242-243 of PROFIBUS side
03
Function Description
Output Bytes 0-1 of PROFIBUS side
06/16
Output Bytes 2-3 of PROFIBUS side
06/16
Output Bytes 4-5 of PROFIBUS side
06/16
Output Bytes 242-243 of PROFIBUS side
06/16
INFO:
