M S :
ODULE ELECTION
The section "Module Selection" is used to select which
Modules are present in the Slave (Fig. 7).
In this section is possible to:
Check the list of the Modules selected ("Select
Modules") (Fig. 7, point (1)) and the list of Modules
Available in GSD file ("Available Modules") (Fig. 7,
point (7));
Add a Module from the list of GSD file (Fig. 7, point
(6));
Remove a Module from selected list (Fig. 7, point
(5));
Add all Modules present in the GSD file (Fig. 7, point
(4));
Remove all Modules from selected list (Fig. 7, point
(3));
Insert a Module not present in the GSD file
Module") (Fig. 7 point (2)). For more info see the
section "Manual Module" below;
Enable the read of configuration directly from the
PROFIBUS Slave ("Use
device") (Fig 7, point (8)). If this
readed from
option is enable the configuration of the modules is
discorded and the
configuration directly to the PROFIBUS slave.
ADFweb.com Srl – IT31010 – Mareno – Treviso
("Manual
module configuration
device read the correct
User Manual PROFIBUS Master / Modbus TCP Slave - Converter
Document code: MN67579_ENG
Figure 7: "PROFIBUS Device – Module Selection" window
