Industrial Electronic Devices
U
P
:
SER
ARAMETERS
The section "User Parameters" is used to modify the parameters of the PROFIBUS slave (Fig. 9).
In this section there are:
The List of all Parameters available for the
PROFIBUS device ("User Parameters") (Fig.
9, point (1));
The Configuration of all parameters in RAW
("Parameters
in
RAW
point(2));
The
"Use Parameter Inserted
enable this option is possible to insert
manually the parameters of Device and also
of the Modules. Using the
Parameters
Manually" button is possible to
insert/modify the parametrization
device (and/or modules). For more info see
below. (Fig. 9, point(3));
The
admited
value
parameter. It is possible to select the value
desired and confirm it with the "Apply"
button. If no value appears in this table, the
"Min Value" and "Max Value" are the limit of
the parameter. (Fig. 9, point(4));
The "Apply" button is used to confirm the
new value of the parameter, the "Default"
button is used to load the factory value for
the parameter. In
"New
possible to set the new value. (Fig. 9,
point(5)).
ADFweb.com Srl – IT31010 – Mareno – Treviso
(Hex)")
(Fig.
9,
Manually",
"Modify User
of the
for
the
selected
Value" edit box it is
Figure 9: "PROFIBUS Device – User Parameters" window
User Manual PROFIBUS Master / Modbus TCP Slave - Converter
Document code: MN67579_ENG
INFO:
www.adfweb.com
Revision 2.002
Page 20 of 32
