Industrial Electronic Devices
User Manual
Revision 1.001
English
BACnet Master / PROFIBUS Slave - Converter
(Order Code: HD67716-IP-A1, HD67716-MSTP-A1)
For Website information:
www.adfweb.com?Product=HD67716
For Price information:
www.adfweb.com?Price=HD67716-IP-A1
www.adfweb.com?Price=HD67716-MSTP-A1
Benefits and Main Features:
Very easy to configure
Triple Electrical isolation
Temperature range: -40°C/+85°C (-40°F/+185°F)
User Manual
ADFweb.com S.r.l.
User Manual BACnet Master / PROFIBUS Slave
Document code: MN67716_ENG
For other BACnet Master products see also the following link:
Converter BACnet Master to
www.adfweb.com?Product=HD67704
www.adfweb.com?Product=HD67712
www.adfweb.com?Product=HD67714
www.adfweb.com?Product=HD67717
www.adfweb.com?Product=HD67718
www.adfweb.com?Product=HD67719
www.adfweb.com?Product=HD67721
www.adfweb.com?Product=HD67722
www.adfweb.com?Product=HD67723
www.adfweb.com?Product=HD67725
www.adfweb.com?Product=HD67726
www.adfweb.com?Product=HD67801
www.adfweb.com?Product=HD67832
Do you have your customer protocol? Then go to:
www.adfweb.com?Product=HD67003
Do you need to choose a device? Do you want help?
www.adfweb.com?Cmd=helpme
Revision 1.001
Page 1 of 28
(DMX)
(Modbus Slave)
(Modbus TCP Slave)
(CAN)
(CANopen)
(PROFINET)
(DeviceNet Slave)
(EtherNet/IP)
(NMEA 2000)
(J1939)
(SNMP Agent)
(KNX)
(DALI)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ADF Web HD67716-IP-A1
Summary of Contents for ADF Web HD67716-IP-A1
- Page 1 Revision 1.001 Page 1 of 28 Industrial Electronic Devices User Manual Revision 1.001 English BACnet Master / PROFIBUS Slave - Converter (Order Code: HD67716-IP-A1, HD67716-MSTP-A1) For Website information: www.adfweb.com?Product=HD67716 For Price information: www.adfweb.com?Price=HD67716-IP-A1 www.adfweb.com?Price=HD67716-MSTP-A1 Benefits and Main Features: Very easy to configure...
-
Page 2: Table Of Contents
User Manual BACnet Master / PROFIBUS Slave Document code: MN67716_ENG Revision 1.001 Page 2 of 28 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Page Dear customer, we thank you for your attention and we remind you that INDEX you need to check that the following document is: UPDATED DOCUMENTATION Updated REVISION LIST... -
Page 3: Security Alert
User Manual BACnet Master / PROFIBUS Slave Document code: MN67716_ENG Revision 1.001 Page 3 of 28 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application. -
Page 4: Example Of Connection
User Manual BACnet Master / PROFIBUS Slave Document code: MN67716_ENG Revision 1.001 Page 4 of 28 Industrial Electronic Devices EXAMPLES OF CONNECTION: ADFweb.com S.r.l. -
Page 5: Connection Scheme
User Manual BACnet Master / PROFIBUS Slave Document code: MN67716_ENG Revision 1.001 Page 5 of 28 Industrial Electronic Devices CONNECTION SCHEME: Figure 1a: Connection scheme for HD67716-IP-A1 ADFweb.com S.r.l. - Page 6 User Manual BACnet Master / PROFIBUS Slave Document code: MN67716_ENG Revision 1.001 Page 6 of 28 Industrial Electronic Devices Figure 1b: Connection scheme for HD67716-MSTP-A1 ADFweb.com S.r.l.
-
Page 7: Characteristics
User Manual BACnet Master / PROFIBUS Slave Document code: MN67716_ENG Revision 1.001 Page 7 of 28 Industrial Electronic Devices CHARACTERISTICS: The HD67716 is a BACnet Master / PROFIBUS Slave - Converter. They allows the following characteristics: Up to 512 BACnet objects in reading and 512 objects in writing; Triple isolation between PROFIBUS - Power Supply, PROFIBUS - BACnet, BACnet - Power Supply;... -
Page 8: Power Supply
The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below. Vmin Vmax Vmin Vmax Consumption at 24V DC: Device Consumption [W/VA] HD67716-IP-A1 HD67716-MSTP-A1 Caution: Do not reverse the polarity power HD67716-IP-A1 HD67716-MSTP-A1 ADFweb.com S.r.l. -
Page 9: Function Modes
User Manual BACnet Master / PROFIBUS Slave Document code: MN67716_ENG Revision 1.001 Page 9 of 28 Industrial Electronic Devices FUNCTION MODES: The device has got two function modes depending on the position of the ‘Dip2 of Dip-Switch A’: The first, with ‘Dip2 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device. The second, with ‘Dip2 of Dip-Switch A’... -
Page 10: Leds
User Manual BACnet Master / PROFIBUS Slave Document code: MN67716_ENG Revision 1.001 Page 10 of 28 Industrial Electronic Devices LEDS: The device has got six LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode ON: Device powered... -
Page 11: Ethernet
ETHERNET: The BACnet/IP connection must be made using Connector3 and/or Connector4 of HD67716-IP-A1 with at least a Category 5E cable. The maximum length of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. -
Page 12: Profibus
User Manual BACnet Master / PROFIBUS Slave Document code: MN67716_ENG Revision 1.001 Page 12 of 28 Industrial Electronic Devices PROFIBUS: The PROFIBUS uses a 9-pin D-SUB connector. The pin assignment is defined like in the right figure. Here some codes of cables: Belden: p/n 183079A - Continuous Armor DataBus®... -
Page 13: Use Of Compositor Sw67716
User Manual BACnet Master / PROFIBUS Slave Document code: MN67716_ENG Revision 1.001 Page 13 of 28 Industrial Electronic Devices USE OF COMPOSITOR SW67716: To configure the Converter, use the available software that runs with Windows called SW67716. It is downloadable on the site www.adfweb.com and its operation is described in this document. -
Page 14: New Configuration / Open Configuration
User Manual BACnet Master / PROFIBUS Slave Document code: MN67716_ENG Revision 1.001 Page 14 of 28 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a programmable “BACnet Master / PROFIBUS Slave - Converter”... -
Page 15: Software Options
User Manual BACnet Master / PROFIBUS Slave Document code: MN67716_ENG Revision 1.001 Page 15 of 28 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor. - Page 16 User Manual BACnet Master / PROFIBUS Slave Document code: MN67716_ENG Revision 1.001 Page 16 of 28 Industrial Electronic Devices In the section “Software Settings”, it is possible to enable/disable some keyboard’s commands for an easier navigation inside the tables contained in the different sections of the software.
-
Page 17: Set Communication
User Manual BACnet Master / PROFIBUS Slave Document code: MN67716_ENG Revision 1.001 Page 17 of 28 Industrial Electronic Devices SET COMMUNICATION: This section define the fundamental communication parameters of two buses, BACnet and PROFIBUS. By Pressing the “Set Communication” button from the main window for SW67716 (Fig. 2) the window “Set Communication”... - Page 18 User Manual BACnet Master / PROFIBUS Slave Document code: MN67716_ENG Revision 1.001 Page 18 of 28 Industrial Electronic Devices If selected “BACnet MS/TP”, the means of the fields for “BACnet” are: In the field “Baudrate” the data rate of the BACnet line is defined; In the field “Parity”...
-
Page 19: Set Bacnet Access
User Manual BACnet Master / PROFIBUS Slave Document code: MN67716_ENG Revision 1.001 Page 19 of 28 Industrial Electronic Devices SET BACNET ACCESS: By Pressing the “Set BACnet Access ” button from the main window of SW67716 (Fig. 2), the window “Set BACnet Access” appears (Fig. Figure 4a: “BACnet Set Access BACnet Read”... - Page 20 User Manual BACnet Master / PROFIBUS Slave Document code: MN67716_ENG Revision 1.001 Page 20 of 28 Industrial Electronic Devices In the field “D Adr” the address of the endpoint is defined. If “D Len” is ‘1’, it is possible to insert a number from 1 to 255; if “D Len” is ‘2’, it is possible to insert a number from 1 to 65535;...
- Page 21 User Manual BACnet Master / PROFIBUS Slave Document code: MN67716_ENG Revision 1.001 Page 21 of 28 Industrial Electronic Devices Figure 4b: “BACnet Set Access BACnet Write” window The means of the fields in the window (Write) are the follows: In the field “IP Address/ID”...
-
Page 22: Gsd File
User Manual BACnet Master / PROFIBUS Slave Document code: MN67716_ENG Revision 1.001 Page 22 of 28 Industrial Electronic Devices In the field “Max Error” the number of consecutive errors that the Master waits before discard the row from the cycle of requests is defined;... -
Page 23: Update Device
User Manual BACnet Master / PROFIBUS Slave Document code: MN67716_ENG Revision 1.001 Page 23 of 28 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary. If you don’t know the actual IP address of the device you have to use this procedure: Turn OFF the Device;... - Page 24 User Manual BACnet Master / PROFIBUS Slave Document code: MN67716_ENG Revision 1.001 Page 24 of 28 Industrial Electronic Devices Note: When you install a new version of the software, if it is the first time it is better you do the update of the Firmware in the HD67716 device.
-
Page 25: Mechanical Dimensions
User Manual BACnet Master / PROFIBUS Slave Document code: MN67716_ENG Revision 1.001 Page 25 of 28 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 7a: Mechanical dimensions scheme for HD67716-IP-A1 Figure 7b: Mechanical dimensions scheme for HD67716-MSTP-A1 ADFweb.com S.r.l. -
Page 26: Ordering Informations
BACnet type IP: BACnet/IP MSTP: BACnet MS/TP Device Family HD67716: BACnet Master / PROFIBUS Slave - Converter Order Code: HD67716-IP-A1 BACnet/IP Master / PROFIBUS Slave – Converter Order Code: HD67716-MSTP-A1 BACnet MS/TP Master / PROFIBUS Slave – Converter ACCESSORIES: Order Code: AC34001 35mm Rail DIN - Power Supply 220/240V AC 50/60Hz –... -
Page 27: Disclaimer
User Manual BACnet Master / PROFIBUS Slave Document code: MN67716_ENG Revision 1.001 Page 27 of 28 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user. -
Page 28: Warranties And Technical Support
User Manual BACnet Master / PROFIBUS Slave Document code: MN67716_ENG Revision 1.001 Page 28 of 28 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following:...
