By pressing the "Modify User Parameters
window appears (Fig. 10).
In this window is possible to add/modify the User and/or Modules Parameters
manually, i.e. writing the configuration of the parameters (in hexadecimal).
The means of the fields are:
In the field "Insert the number of User
byte for the parameter have to be inserted;
In the field "Insert the Configuration of Module
configuration of the User and/or Modules Parameters is defined. The
configuration must be write in hexadecimal mode (without prefix "0x"
o "$").
Note:
The Values inserted in the table must between 00 and FF
ADFweb.com Srl – IT31010 – Mareno – Treviso
User Manual PROFIBUS Master / Modbus TCP Slave - Converter
Manually" button from the "PROFIBUS Device" window (Fig. 6) the "Add Module Manually"
Parameter" the number of
(HEX)" the
Document code: MN67579_ENG Revision 2.002
Figure 10: "Add/Modify User Parameters Manually" window
