ADF Web HD67012 User Manual

Can / modbus slave - converter

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Industrial Electronic Devices

User Manual

Revision 2.101

English

CAN / Modbus Slave - Converter

(Order Code: HD67012)

for Website information:

www.adfweb.com?Product=HD67012

for Price information:

www.adfweb.com?Price=HD67012

Benefits and Main Features:

Very easy to configure

Low cost

Rail mountable

Wide supply input range

Galvanic isolation

Industrial temperature range:

-40°C / 85°C (-40°F / 185°F)

ADFweb.com Srl – IT31010 – Mareno – Treviso

User Manual CANbus / Modbus Slave

Document code: MN67012_ENG

Similiar

Products

For other Gateways / Bridges:

CAN to Modbus

Need help?

Do you have a question about the HD67012 and is the answer not in the manual?

Questions and answers

Summary of Contents for ADF Web HD67012

Page 1 Document code: MN67012_ENG Revision 2.101 Page 1 of 17 Industrial Electronic Devices User Manual Revision 2.101 English CAN / Modbus Slave - Converter (Order Code: HD67012) for Website information: www.adfweb.com?Product=HD67012 HD67012 for Price information: www.adfweb.com?Price=HD67012 Similiar Products For other Gateways / Bridges:...
Page 2: Table Of Contents
User Manual CANbus / Modbus Slave Document code: MN67012_ENG Revision 2.101 Page 2 of 17 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Page Dear customer, we thank you for your attention and we remind you that you need to check that the following document is: INDEX Updated UPDATED DOCUMENTATION...
Page 3: Security Alert
User Manual CANbus / Modbus Slave Document code: MN67012_ENG Revision 2.101 Page 3 of 17 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device are required for each individual application, legal and safety regulation.
Page 4: Characteristics
The Converter can be configured up to a maximum 250 CANbus frame in reading and 250 CANbus frame in writing. CONNECTION SCHEME: Figure 1: Connection scheme of HD67012 between a CANbus and Modbus RTU ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com...
Page 5 = Yes Jumper No Boot Mode: Side A Side B Boot Mode Change when CAN message arrive = No Jumper Normal Mode Figure 2: Connection scheme for HD67012 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 6: Configuration
User Manual CANbus / Modbus Slave Document code: MN67012_ENG Revision 2.101 Page 6 of 17 Industrial Electronic Devices CONFIGURATION: The “Gateway CANbus to Modbus” allows a CANbus network to communicate with a Modbus network. You need Compositor SW67012 software on your PC in order to perform the following: Define that the CANbus frame of the CANbus are reading from Modbus;...
Page 7: New Project / Open Project
User Manual CANbus / Modbus Slave Document code: MN67012_ENG Revision 2.101 Page 7 of 17 Industrial Electronic Devices NEW PROJECT / OPEN PROJECT: The “New Project” button creates the folder which contains the entire device configuration. A device configuration can also be imported or exported: To clone the configurations of a Programmable CANbus to Modbus Gateway in order to configure another device in the same manner, it is necessary to maintain the folder and all its contents;...
Page 8: Set Communication
User Manual CANbus / Modbus Slave Document code: MN67012_ENG Revision 2.101 Page 8 of 17 Industrial Electronic Devices SET COMMUNICATION: This section defines the fundamental communication parameters of two Buses, CANbus and Modbus. By pressing the “Set Communication” button from the main window for SW67012 (Fig. 3) the window “Set communication”...
Page 9: Recive Cob
User Manual CANbus / Modbus Slave Document code: MN67012_ENG Revision 2.101 Page 9 of 17 Industrial Electronic Devices RECEIVE COB: By pressing the “Receive COB” button from the main window for SW67012 (Fig. 3) the window “Receive CAN Frame” appears (Fig. 5). A user who has to read a CANbus frame from CANbus to Modbus needs to insert the coordinates of the CANbus frame in order to be transmitted in the field “Receive COB”...
Page 10: Define Cob
User Manual CANbus / Modbus Slave Document code: MN67012_ENG Revision 2.101 Page 10 of 17 Industrial Electronic Devices DEFINE COB: By pressing the “Define COB” button from the main window for SW67012 (Fig. 3) the window “Receive CAN Frame Info” appears (Fig. 6). In the field “COB-ID Frame”...
Page 11: Transmit Cob
User Manual CANbus / Modbus Slave Document code: MN67012_ENG Revision 2.101 Page 11 of 17 Industrial Electronic Devices TRANSMIT COB: By pressing the “Transmit COB” button from the main window for SW67012 (Fig. 3) the window “Transmit CAN Frame” appears (Fig. 7). A user who has to write a CANbus frame from Modbus to CANbus needs to insert the coordinates of the CANbus frame in order to be transmitted in the field “Trasmit COB”...
Page 12: Define Cob
User Manual CANbus / Modbus Slave Document code: MN67012_ENG Revision 2.101 Page 12 of 17 Industrial Electronic Devices DEFINE COB: By pressing the “Define COB” button from the main window for SW67012 (Fig. 3) the window “Transmit CAN Frame Info” appears (Fig. 8). In the field “COB-ID Frame”...
Page 13: Update Device
User Manual CANbus / Modbus Slave Document code: MN67012_ENG Revision 2.101 Page 13 of 17 Industrial Electronic Devices UPDATE DEVICE: Section “Update Device”: Insert the boot jumper (see figure 2). In order to load the parameters after they are set, set the Com port you used for update, then you must click the button “Execute update firmware”...
Page 14: Characteristics Of The Cables
User Manual CANbus / Modbus Slave Document code: MN67012_ENG Revision 2.101 Page 14 of 17 Industrial Electronic Devices CHARACTERISTICS OF THE CABLES: The connection from RS232 socket to a serial port (example one from a personal computer) must be made with a Null Modem cable (a serial cable where the pins 2 and 3 are crossed).
Page 15: Mechanical Dimensions
Page 15 of 17 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 10: Mechanical dimensions scheme ORDER CODE: Order Code: HD67012 CAN / Modbus Slave - Converter ACCESSORIES: Order Code: AC34107 Null Modem Cable Fem/Fem DSub 9 Pin 1,5 m Order Code: AC34114...
Page 16: Disclaimer
User Manual CANbus / Modbus Slave Document code: MN67012_ENG Revision 2.101 Page 16 of 17 Industrial Electronic Devices DISCLAIMER All technical content within this document can be modified without notice. The content of the document content is a recurring audit. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user.
Page 17: Warranties And Technical Support
PRODUCTS AND RELATED DOCUMENTS: Part Description HD67117 CAN bus Repeater www.adfweb.com?Product=HD67117 HD67216 CAN bus Analyzer www.adfweb.com?Product=HD67216 HD67012 CAN bus to Modbus RTU Client www.adfweb.com?Product=HD67012 HD67014 CAN bus to Modbus TCP Client www.adfweb.com?Product=HD67014 HD67515 CAN bus to Modbus TCP Server www.adfweb.com?Product=HD67515 ADFweb.com Srl –...
