Chapter 2: Jumpers and Connectors
Internal Connectors
BIOS Pin Header
Connector type: 2x3 6-pin Wafer, 2.0mm pitch
Connector location: JFW1
2
6
1
5
Pin
Definition
1
VCC
3
CS#0
5
SO
Copyright © 2015 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
2
GND
4
CLK
6
SI
SATA Connector
Connector type: Standard Serial ATA 7P (1.27mm, SATA-M-180)
Connector location: CN13
1
7
Pin
Definition
1
GND
3
SATA_TXN0_C
5
SATA_RXN0_C
7
GND
20
Pin
Definition
2
SATA_TXP0_C
4
GND
6
SATA_RXP0_C
