Chapter 3: System Setup
Installing a Mini-PCIe Module (Full-size)
1. Insert the wireless LAN module into the mini-PCI Express slot at a 45
degree angle until the gold-plated connector on the edge of the module
completely disappears inside the slot.
Copyright © 2015 NEXCOM International Co., Ltd. All Rights Reserved.
2. Push the module down and then secure it with mounting screws.
31
Mounting
screw
NISE 50C/50C-H User Manual
