Chapter 2: Jumpers and Connectors

Connector Pin Definitions

Internal Connectors

M.2 Key B Conector

Connector type: M.2 3042/3052 Key B slot for LTE/5G FR1 module
Connector location: 5G_1
1 75
2 74
Pin Definition
1 5G_1_CONFIG_3
3 GND
5 GND
7 USB2_P7_5G_C_DP
9 USB2_P7_5G_C_DN
11 GND
13 -
15 -
17 -
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
2 +P3V3_5G
4 +P3V3_5G
6 5G_1_POWER_OFF_R_N
8 5G_1_WWAN_DIS_N
10 NC
12 -
14 -
16 -
18 -
Pin Definition
19 -
21 5G_1_CONFIG_0
23 5G_1_WAKE_N
25 NC
27 GND
29 USB32_P1_5G_RXN
31 USB32_P1_5G_RXP
33 GND
35 USB32_P1_5G_TXN
9
Pin Definition
20 NC
22 NC
24 NC
26 5G_1_GNSS_DIS_N
28 NC
30 5G_1_SIM1_RST
32 5G_1_SIM1_CLK
34 5G_1_SIM1_DATA
36 5G_1_SIM1_VDD_F
Continued on next page
