Chapter 2: Jumpers and Connectors

SATA Power Connector

Connector type: 1x2 2-pin header, 2.0mm pitch
Connector location: J4
2 1
Pin Definition
1 VCC5
2 GND
Copyright © 2015 NEXCOM International Co., Ltd. All Rights Reserved.

GPIO Pin Header

Connector type: 2x5 10-pin header, 2.0mm pitch
Connector location: JP3
2 10
1 9
Pin Definition
1 VCC5
3 ICH_GPO0_OUT
5 ICH_GPO1_OUT
7 ICH_GPO2_OUT
9 ICH_GPO3_OUT
21
Pin Definition
2 GND
4 ICH_GPI0_IN
6 ICH_GPI1_IN
8 ICH_GPI2_IN
10 ICH_GPI3_IN
