Chapter 2: Jumpers and Connectors
ME Clear Select
Connector type: 1x3 3-pin header, 2.54mm pitch
Connector location: JP5
1
3
Pin
Settings
1-2 On
Normal
2-3 On
Clear ME
1-2 On: default
Pin
Definition
1
NC
2
SRTC_TEST#
3
GND
Copyright © 2015 NEXCOM International Co., Ltd. All Rights Reserved.
13
NISE 50C/50C-H User Manual
